Removing And Installing Handlebar Grip Unit; Removing And Installing Left Handlebar Grip Unit - BMW R 1150 RT Repair Manual

7
6
Removing and installing
32 72
handlebar grip unit
Removing and installing left
32 72 065
handlebar grip unit
1
2
•
[Radio] Remove screw (1) at handlebar remote-
control unit.
•
[Radio] Remove housing cover of handlebar re-
mote-control unit.
•
[Radio] Remove screws (2) and screw (3) and
remove housing of handlebar remote-control
unit.
10
9
11
8
5
3
•
[Heated grips] Open cable ties of left heated
grip up to plug (4).
•
[Heated grips] Disconnect plug from heated
grip.
•
[Heated grips] Release cable shoe in connec-
tion and pull out the cable.
R22320030
9
4
R22320010
R22610060
32.5
