２-２-１１. Attacking Duck - Robotis Beginner level robot series Quick Start Manual

Beginner Level Robot Series
２-２-１１. Attacking Duck
Let's build a duck robot that attack with a beak when the sensor detects an object.
(1) Necessary parts
1 2 3
CM-5
motor motor motor
AX-12 × 3 AX-S1
ADAPTOR-CM5
F1 × 1 F2 × 1 F3 × 5 F9 × 1 F11 × 1 BU × 2
WA × 2
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
N1 × 40
CABLE-10
× 2
S1 × 56
× 2
CABLE-14
S-B × 2
