２-２-７. Melody Car
Let's build a melody car that chimes and moves in a direction corresponding to a button
(1) Necessary parts
1 2 3 4
CM-5
motor motor motor motor
AX-12 × 4 AX-S1
ADAPTOR-CM5
F3 × 6 F13 × 4 F14 × 4 Sticker × 10
※Nuts, screws, and cables shown below are the same as the actual size. Place and measure the parts
against the below illustration to choose the correct assembly part.
CABLE-6 × 2
N1 × 48
S1 × 48
CABLE-10
× 2
S2 × 16
× 1
CABLE-14
