Figure 2.4-3 depicts the LIB SLC numbering scheme for an AM2020 in a CAB-D3 cabinet. Three ICA-4L chassis
are required to mount the various types of LIB modules employed. Refer to Figure 2.4-2 as an example of
AFP1010 applications.
NOTE
The installation of LIB modules resulting in duplicate LIB SLC numbers is never permitted.
.4-3
1-20
Installation 15088:J
10/22/99
