PN 51010:C1
ECN 01-552
Intelligent Fire Panel
AFP-100/AFP-100E
Instruction Manual
C1
Document 51010
02/06/2002
Rev:
Technical Manuals Online! - http://www.tech-man.com

Advertisement

Table of Contents
loading

Related Manuals for Notifier AFP-100

Summary of Contents for Notifier AFP-100

  • Page 1 PN 51010:C1 ECN 01-552 Intelligent Fire Panel AFP-100/AFP-100E Instruction Manual Document 51010 02/06/2002 Rev: Technical Manuals Online! - http://www.tech-man.com...

  • Page 2: Fire Alarm System Limitations

    (especially in bedrooms), smoking in bed, and violent explosions (caused by escaping gas, improper storage of flammable materials, etc.). Precau-L-11-2001.fm AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 3: Installation Precautions

    Acclimate Plus™, HARSH™, NOTI•FIRE•NET™, ONYX™, and VeriFire™ are trademarks, and FlashScan® and VIEW® are registered trademarks of NOTIFIER. NION™ and UniNet™ are trademarks of NIS. NIS™ and Notifier Integrated Systems™ are trademarks and NOTIFIER® is a registered trademark of Fire•Lite Alarms, Inc. Echelon® is a registered trademark and LonWorks™ is a trademark of Echelon Corporation. ARCNET® is a registered trademark of Datapoint Corporation.
  • Page 4 This page intentionally left blank AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 5 $QQXQ.LDWRU &RQWURO 0RGXOH  $&0$   $QQXQ.LDWRU ([SDQGHU 0RGXOH  $(0$   $QQXQ.LDWRU )L[HG 0RGXOHV  $QQXQ.LDWRU )L[HG 0RGXOH  $)0$7   $QQXQ.LDWRU )L[HG 0RGXOH  $)0$   AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 6 3URJUDPPLQJ  5HDG 6WDWXV  $&%$7   (QWHU 3URJUDPPLQJ 0RGH  3DVVZRUGV   3URJUDP &KDQJH ± /HYHO 2QH   &OHDU   $XWRSURJUDP   1HZ 'HWH.WRUV  AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 7 $XWRVLOHQ.H 7LPHU 1RQH RU  0LQXWHV   7URXEOH 5HPLQGHU   $ODUP 9HULIL.DWLRQ 1RQH RU  6H.RQGV   :DWHUIORZ &LU.XLWV 2SHUDWLRQ   'LVDEOH(QDEOH 2SHUDWLRQ   :LULQJ )DXOW   5HDG 6WDWXV   AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 8 3URSULHWDU\ )LUH $ODUP 6\VWHP   &HQWUDO 5HPRWH 6WDWLRQ 6HUYL.H 3URWH.WHG 3UHPLVHV 8QLW   $X[LOLDU\ )LUH $ODUP 6\VWHP   5HPRWH 6WDWLRQ 3URWH.WLYH 6LJQDOLQJ 6\VWHP   3URSULHWDU\ 3URWH.WLYH 6LJQDOLQJ 6\VWHPV  AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 9: Product Description

    The AFP-100E offers the same features as the AFP-100 but allows connections to 220/240 VAC input. Note: Unless otherwise specified the term “control panel” or AFP-100 refers to both the AFP-100 and the AFP-100E Fire Alarm Control Panel.

  • Page 10: Supplemental Documentation

    LCD-2X20 Remote Fire Annunciator Manual 51105 Universial Digital Alarm The UDACT Instruction Manual 50050 Communicator/Transmitter Digital Communications MS-5012 Control Communicator Manual 15465 Fire Alarm Receiver RS-82 Receiving Station Manual 15400 Table 1 Supplemental Documentation AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 11: Main Circuit Board

    HIGH VOLTAGE BATTERY Cabinet The AFP-100 cabinet door is gray with a navy blue front overlay. The backbox is ordered separately. The Main Circuit Board is mounted onto rails of the backbox. Ample knockouts are provided for system wiring. Transformer Assembly One XRM-24 (XRM-24E for 220/240 VAC applications) 100 VA transformer, providing 3.6 amps...

  • Page 12: Controls And Indicators

    If AC power is lost and the system is not in alarm, the LED backlight will turn off to conserve batteries. Local Sounder The control panel has a local sounder to provide separate and distinct pulse rates for alarm, trouble, and supervisory conditions. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 13 Terminals, Connectors & Switches 1. Product Description Terminals, Connectors & Switches The figure below shows the terminals, connectors and switches that are located on the AFP-100 main circuit board. TB3 - Relays TROUBLE ALARM SUPV TERM COMM TB1 - NAC Circuit 1...

  • Page 14: Signaling Line Circuit (Slc)

    Three dry contact relays are provided for System Alarm and System Trouble (Form-C contacts) and Supervisory (Form-A contacts). Contacts are rated 2.0 amps @ 30 VDC (resistive) and 0.5 amps @ 30 VAC (resistive). AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 15: Accessories And Options

    The BB-17 battery box may be used to house two 18 AH batteries. The battery box mounts directly below the AFP-100 cabinet. The BB-55 battery box may be used to house two 25 AH batteries, two 55 AH batteries or one 100 AH battery. Both boxes are gray and provided with knockouts.

  • Page 16: Programming Utility

    IBM compatible personal computers, including laptops and portables, equipped with a serial port. Typically, program files can also be created and stored on the PC, then downloaded to the control panel. The software is on a CD (compact disk). AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 17: Addressable Devices

    FSD-751 - Photoelectric Duct Detector. The FSD-751RP includes an alarm relay. HPX-751 - A special smoke detector that provides early warning smoke detection in hostile environments where traditional smoke detectors are not practical. FSI-751 and FSP-751 FST-751 AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 18: Bases And Accessories

    An addressable module that is functionally similar to an FMM-1 LOOP Monitor Module —but offered in a smaller package for mounting TENS ONES directly in the electrical box of the device being monitored. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 19: Fault Isolator Module - Ixo-X

    Pull Station - NBG-12LX A non-coded addressable manual pull station with key-lock reset feature. An FSM-101addressable module is housed within the pull station. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 20: Optional Internal Modules

    1. Product Description Optional Internal Modules Optional Internal Modules The AFP-100 main circuit board includes option module connectors which are located on the right side of the board. Available optional modules are as follows: RTM-8F Relay/Transmitter Module The RTM-8F provides eight high current (5 amps) Form-C relays. These relays track software zones 1 through 8.

  • Page 21: Acs Series Led Zone Type Annunciators

    For information and installation instructions refer to Annunciator Control System manual. Refer to "System Edit" on page 49, for information on programming the AFP-100 for annunciator use. Below are brief descriptions of Annunciator Control and Annunciator Expander Modules used with the control panel.

  • Page 22: Annunciator Fixed Modules

    Power-limited, filtered, nonresettable power must be supplied by the FACP. For more information and installation instructions refer to the ACM-8R Annunciator Relay Control Module manual. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 23: Lcd-2X20 Series Remote Fire Annunciators

    Expands the LDM-32 by 32 system points, to a maximum of 64 points Lamp Driver Relay Expander Module - LDM-R32 Provides the LDM-32 or LDM-E32 with 32 dry Form-A (normally open) contacts. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 24 1. Product Description Annunciators Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 25: Installation

    Checklist The table below contains an installation checklist for installing, wiring and testing an AFP-100 system. It has referances to installation information not included in this manual. Task...

  • Page 26: Cabinet Mounting

    2. Installation Cabinet Mounting Cabinet Mounting This section provides instructions for mounting the AFP-100 cabinet. Follow these guidelines when mounting the backbox: Caution: Unless you are familiar with the placement of components within this cabinet, only use the knockout locations provided for conduit entry.
  • Page 27 Cabinet Mounting 2. Installation Shown below are dimensions for the AFP-100 cabinet. TR-4-R Trim Ring Figure 5 AFP-100 Cabinet Dimensions AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 28: Component Installation

    NO C NO NC C NO NC C OUT+ IN+ OUT- IN- A+ B- A- 1 CO MM 2 CAUTION G ND FA ULT HIGH VOLTAGE BA TT ERY Figure 6 Component Mounting AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 29: Power Connections

    AC Connections Primary power required for the AFP-100 control panel is 110/120 VAC, 60 Hz, 2.3 amps and for the AFP-100E is 220/240 VAC, 50 HZ, 1.2 amps.

  • Page 30: Battery (Dc) Connections

    Connect red wire to positive (+) terminal and black wire to negative (–) terminal on opposing batteries. BATTERY Battery Cable PN 75203 Battery Interconnect Cable Figure 8 Battery Connections AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 31: Dc Power Output Connections

    Figure 9 DC Power Outputs (TB4) Standard Relays Circuits Through terminal block TB3 the AFP-100 provides a set of Form-C alarm and Form-C trouble contacts rated for 2.0 amps @ 30 VDC (resistive). The control panel also provides a Form-A supervisory contact rated for 2.0 amps @ 30 VDC (resistive).

  • Page 32: Annunciator Circuits

    Note that TB7 Out and In polarities are used for connecting Terminal Mode annunciators. Note: Devices connected to the standard EIA-485 connector, the optional EIA-232/EIA-485 connector may be protected from voltage transients by using one of the UL-listed compatible surge suppressors listed in the Notifier Device Compatibility Document. EIA-485 connection for EIA-485 connection for ACS Terminal Mode annunciator.

  • Page 33: Device Capacity

    NFPA Style 4, Style 6 or Style 7. Device Capacity The capacity of the AFP-100 includes up to 99 addressable detectors and an additional combination of up to 99 addressable pull stations, control modules, and monitor modules. In addition, the control panel supports two NACs.

  • Page 34: Ul Power-Limited Wiring Requirements

    All power-limited circuit wiring must remain at least 0.25 inches (6.35 mm) away from any nonpower-limited circuit wiring. Furthermore, all power-limited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through different knockouts and/or conduits. A typical wiring diagram for the AFP-100 is shown below. Power-limited Nonpower-limited Power-limited...

  • Page 35: Installing A Rtm-8F Module

    OUT+ IN+ OUT- IN- 1 COMM 2 3/4 inch nylon standoffs RTM-8F AFP-100 Main Circuit Board 3/4 inch aluminum standoff with nut (Required for transient protection) Figure 14 RTM-8F Module Installation AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 36 (such as the Fire•Lite RS-82 Receiving Station) having compatible ratings. The RTM-8F is not suitable for separate transmission of both alarm and trouble signals simultaneously to a remote station. Output is power-limited and wiring can leave the building. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 37 Trouble LED will remain on. Transmitter 1N4004 Output Figure 16 Transmitter Output Dummy Load Caution: The diode must be removed when using the Transmitter Output to properly supervise the connections. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 38 Installation of a printer or PC requires an interface cable prewired to a DB9F connector (see below). Connect the interface cable to TB7 on the AFP-100 main circuit board and the attached cable to the EIA-232 serial port on the printer or PC, as shown below. Use a DB25 adapter if a nine pin connector is not available on your PC or printer.

  • Page 39: Printer Configuration

    OPTION SHIELD NO C NO NC C NO NC C PRINTER B B+ A+ B- A- 1 COMM 2 & UP/DOWN LOAD Figure 18 Printer and Computer Connections with PIM-24 AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 40 2. Installation Printer and PC Interface Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 41 To program the system (Program Level 1 and Program Level 2), you must first enter a valid password. Once the correct password is entered, you can select Autoprogram or Program Edit. After programming is completed, return switch SW1 to the Write Protect position. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 42: Initial Power-Up

    NOT password protected. The following screen is displayed upon entering AC/BAT: BATTERY: 24.00 V For the AFP-100 AC LINE: 120.00V For the BATTERY: 24.00 V AFP-100E AC LINE: 240.00V AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 43: Enter Programming Mode

    Entering the Level 2 password (default = 11111) will cause the following screen to appear (refer to "Program Change – Level Two" on page 51): 1=DISABL 2=CLR HIST 3=WALK 4=TIME 5=CHEK AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 44: Program Change - Level One

    Devices which do not match the program (not the same address and/or type) are shown to the operator. Devices inadvertently set to the same address are identified and displayed on the screen. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 45: New Detectors

    FIRST NORTH __2ND SOUTH __3RD _EAST __4TH _WEST __5TH FRONT FLR_1 CENTR FLR_2 _REAR FLR_3 UPPER FLR_4 LOWER FLR_5 _MAIN RM___ Table 3 Adjective Library Continued on the next page... AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 46 4. Press the right arrow key to advance to the Zone field. 5. Select a zone number from 00 to 56. Z00 (default zone) is the general alarm zone. Z01 through Z56 may be selected to link software zones. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 47 Z01 through Z56 if desired. See "Appendix C: Software Zones" on page 80. The ADJ field for monitor modules can also be used to associate a second zone as described in "New Detectors" on page 45. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 48: Control Modules

    49, to select coding. Coding is only possible if the NAC is programmed as 'BELL_CKT'. The point display formats and the method of editing are described in "Autoprogram" on page 44. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 49: System Edit

    The history file will also be updated with this information. For zone annunciation, up to 56 zones, use AFM Series Annunciators or LDM Series Annunciators. For 198 point annunciation, use the LDM Series Annunciators. Table 7 System Function Options AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 50: Password Change

    At the completion of system programming, switch SW1 (Write Protect) should be set to the Write Protect position to prevent inadvertent changes to programmed features. Slide the switch to the up position to select the Write Protect feature. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 51 Note: The control panel only disables initiating devices that are in alarm or control points that are ON occurs after the key is pressed. SYSTEM RESET All disabled points will scroll on the LCD display and the system will remain in trouble until all programmed points are enabled. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 52: Clear History

    This is caused by the temporary removal of 24 VDC resettable power from the FZM-1 and it reports this loss of power as an open condition in addition to the alarm condition. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 53: Open Condition

    At the completion of system programming, switch SW1 (Write Protect) should be set to the Write Protect position to prevent inadvertent changes to programmed features. Slide the switch to the up position to select the Write Protect feature. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 54 3. Programming Program Change – Level Two This page intentionally left blank AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 55: Screen Options Flowchart

    #,NNNNN, E=Level 2 PW V=N I=N A=N P=N C=N Connect Computer Now Autoprogram A/U=M L/P=N S=4 R=N Please Wait Run Program From PC Figure 19 Screen Options Flowchart - 1 AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 56 LEGEND Text inside box actually appears in LCD display Text inside oval indicates key press Write Protect Switch on the AFP-100 circuit board Figure 20 Screen Options Flowchart - 2 AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 57 Screen Options Flowchart 3. Programming Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 58: Control Keys

    “System Reset” in the printer and history file. It also turns on all LEDs, panel sounder and LCD display segments as long as the key is held (lamp test). Any alarm or trouble that exists SYSTEM RESET after pressing the key will resound the system. SYSTEM RESET AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 59: System Status Led Indicators

    The LED turns off when all trouble ACKNOWLEDGE STEP ALARM SILENCE conditions are cleared. This LED will also illuminate if the microprocessor watchdog circuit is activated. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 60: Normal Operation

    • Refreshes the LCD display and updates the system time • Scans the keypad for entries • Performs detector auto test • Tests memory • Update and reads the EIA-485 communications bus AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 61: Trouble Operation

    Fail Automatic Test - indicates that a detector's sensing chamber and electronics (which are tested for normal safe operation every two hours) has failed the test. Table 8 Specific Device Troubles for a Detector AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 62: Monitor And Control Modules

    Open Circuit Monitor/Control Module - indicates an open circuit exists on a control module’s NAC or the monitor module's Initiating Device Circuit. Table 9 Specific Device Troubles for a Module AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 63 ACKNOWLEDGE STEP the control panel displays events in the following priority order: 1. Alarms in address order 2. Supervisories in address order 3. Troubles in address order AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 64: Alarm Operation

    Coded operation includes March Time, Temporal or California types. Refer to "Coded Operation - NAC 01 and NAC 02" on page 66, for additional information on coding. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 65: Control-By-Event (Cbe)Operation

    The control panel includes a crystal-based clock that provides time of day, date and day of week. Time is displayed as 12 hour time with month/day/year and is stored in RAM. If both AC and battery power are lost, the time must be reset. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 66 This does not affect monitor modules programmed as waterflow or supervisory. Note: Presignal operation requires the approval of the local Authority Having Jurisdiction. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 67: Special System Timers

    Alarm Same Detector is Still in Alarm Detector Goes Ignored Into Alarm Different Detector Alarms Control Panel Immediately Processes Alarm During First Detector's Verification Period Figure 23 Alarm Verification Timing AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 68: Waterflow Circuits Operation

    The control panel latches the trouble and displays it until the key is pressed. The display shows Style 6 trouble type. SYSTEM RESET AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 69: Read Status

    2-minute timer. Pressing the left arrow (backspace) key deletes the previous entry. (If there is no previous entry, it will cancel the Read Status operation and return to the previous display.) To cancel Read Status, press the key. SYSTEM RESET AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 70: Display Point

    Print History You can use Print Program function to print the entire 500-event history file. Note: For instructions on connecting a printer, refer to "Printer and PC Interface" on page 38. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 71: Print Detector Data

    Analog Addressable Smoke Detectors 500 - 1400 FSD-751P Intelligent Photoelectric Duct Detectors 500 - 1400 FSD-751RP FST-751 Intelligent Thermal Detectors 600 - 1800 FST-751R Table 12 Acceptable Ranges for Addressable Detectors AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 72: Appendix A: Power Supply Calculations

    Unit Type Total Current of Units (amps) AFP-100 or 2.3 (AFP-100) AFP-100E 1.2 (AFP-100E) CHG-120 Charger XRM-24(E) Transformer Total AC Branch Current Required Amps Table 13 AC Branch Circuit Requirements AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 73: The Main Power Supply

    The Main Power Supply The AFP-100 provides filtered power for operating the fire alarm control panel, operating external devices and operating the standby battery. The power for operating external devices is limited. Use Table 14 on page 73 (standby or nonalarm) and Table 15 on page 74 (alarm) to determine if external loading is within the capabilities of the AFP-100 power supply.
  • Page 74 GUDZ IURP WKH EDWWHULHV WR  DPSV 8. Monitor Module current-limited at 90 mA in alarm. 9. This column must not exceed total system current draw of 6.6 amp. Table 15 Filtered Load in Alarm AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 75: Calculating The Battery Capacity

    • 12 AH to 18 AH batteries require the Notifier BB-17 battery box. • The AFP-100 main circuit board allows disabling of AFP-100 battery charger if using the CHG- 120 Battery Charger for 25 AH to 100 AH batteries (requires separate housing).

  • Page 76: Appendix B: Electrical Specifications

    Appendix B: Electrical Specifications Electrical Specifications Appendix B: Electrical Specifications Electrical Specifications AC Power AFP-100: 120 VAC, 60 Hz, 2.3 amps AFP-100E: 240 VAC, 50 Hz, 1.2 amps Wire size: minimum #14 AWG (2.00 mm ) with 600 VAC insulation Battery...

  • Page 77: Dc Power For Output Circuits

    Connecting external system accessories to the AFP-100 main circuits must be carefully considered to ensure proper operation. It is important to use the correct type of wire, wire gauge and wire run length for each AFP-100 circuit. Reference the chart on next page to specify wire requirements and limitations for each AFP-100 circuit.
  • Page 78 Appendix B: Electrical Specifications Wire Requirements The following table contains wire requirements for the AFP-100: CIRCUIT CONNECTIONS WIRE REQUIREMENTS Recommended Circuit Wire Type and Circuit Type Max. Distance Wire Gauge and Compatible Brands Function Limitations Feet (meters) Connects to Twisted, shielded pair, 10,000 (3,000) 12 AWG (3.25 mm...
  • Page 79 Wire Requirements Appendix B: Electrical Specifications Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 80: Appendix C: Software Zones

    Zone assignment is created via software means, hence the term 'software zones'. Setup of an AFP-100 software zone is straightforward. Any zone may have a minimum of one and a maximum of 198 addressable input devices. Each detector is automatically assigned to a general alarm output (zone Z00).

  • Page 81: Correlation Of Inputs And Outputs To Zones

    The figure below shows examples of software zones for inputs and outputs: INPUT DEVICES OUTPUT DEVICES PHOTO SOFTWARE ZONES PHOTO ZONE CONTROL MONITOR CONTROL MONITOR CONTROL ZONE CONTROL CONTROL PHOTO ZONE PHOTO CONTROL CONTROL Figure 25 Software Zoning Examples AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 82: Sample Programming Sheets

    NOUN (9 char. max) FSP-751 FIRST HALL FSP-751 ELEV. LOBBY FSI-751 2ND FLOOR FSI-751 ROOM 210 FSP-751 3RD FLOOR FSP-751 MEZZANINE FSI-751 MECH. ROOM Table 18 Detector Programming Sheet Example AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 83 MECH. ROOM Table 19 Module Programming Sheet Example The following pages contain: 1) Blank “Zoning Sheet”, 2) Blank “Detector Zone Assignment Sheet” and 3) Blank “Monitor/Control Module Zone Assignment Sheet”. AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 84: Zoning Sheet

    Appendix C: Software Zones Sample Programming Sheets Zoning Sheet OUTPUT DEVICES INPUT DEVICES ZONES AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 85 Appendix C: Software Zones DETECTOR ZONE ASSIGNMENT Device Zone ADJ (5 char. max) Device Zone ADJ (5 char. max) Address Address Type Number NOUN (9 char. max) Type Number NOUN (9 char. max) AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 86 MONITOR/CONTROL MODULE ZONE ASSIGNMENT Device Zone ADJ (5 char. max) Device Zone ADJ (5 char. max) Address Address Type Number NOUN (9 char. max) Type Number NOUN (9 char. max) AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 87 Sample Programming Sheets Appendix C: Software Zones Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 88: Appendix D: Nfpa Standard-Specific Requirements

    Appendix D: NFPA Standard-Specific Requirements Overview Appendix D: NFPA Standard-Specific Requirements Overview The AFP-100 is designed for use in commercial, industrial and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this Appendix. Minimum Requirements...
  • Page 89 1. Program the MS-5012 for slave operation. 2. SW2 Trouble/No AC switch located on the bottom right of the AFP-100 main circuit board, must be positioned in the down position for this application. This prevents the transmission of a trouble on the loss of AC power.
  • Page 90 The following figure illustrates the internal mounting of a UDACT. TROUBLE PC/PRINTER TERM COMM SHIELD OUT+ IN+ OUT- IN- B B+ A+ B- A- 1 COMM 2 Figure 27 Internal installation of UDACT AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 91: Auxiliary Fire Alarm System

    General Notes: 1. The maximum loop resistance allowed for wiring from the AFP-100 to Municipal Box is 3 ohms. 2. Cut JP4 on the AFP-100 main circuit board to supervise placement of RTM-8F module and circuit.

  • Page 92: Remote Station Protective Signaling System

    Remote Station Protective Signaling System General Notes: Cut Jumper JP4 on the AFP-100 main circuit board to supervise placement of the RTM-8F module. 2. Jumper JP1 must be cut for polarity reversal Remote Station operation. 3. Jumper JP2 must be in position ALARM/TROUBLE REVERSE POLARITY for use in alarm and trouble transmission or ALARM ONLY for alarm transmission only.

  • Page 93: Proprietary Protective Signaling Systems

    Appendix D: NFPA Standard-Specific Requirements Proprietary Protective Signaling Systems Notes: Connection between the AFP-100 and the transmitter are supervised by the transmitter. 2. This AFP-100/Transmitter arrangement can be employed for NFPA 72 Proprietary Protective Signaling System. AFP-100 Addressable Fire Control Panel...
  • Page 94 Appendix D: NFPA Standard-Specific Requirements Proprietary Protective Signaling Systems Notes AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 95 Article 760 assignment features audible indication DB25 adapter automatic test DB9F connector 41 45 Autoprogram Feature DC Power Autoprogramming mode connecting Auto-silence Timer outputs available words, list of special purpose specifications AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 96 Four-wire smoke detector power maintenance status FRM-1 Manual Programming Function keys mappable relay control module functions of control panel, normal membrane panel 18 52 FZM-1 Message "Clear Trouble" AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 97 30 32 36 37 polarity 21 22 serial connection Polarity Reversal Output Service/program keys polls short circuits power output connections Shorted/Alarm Condition Power Supply, remote 17 33 76 Signaling Line Circuit AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...
  • Page 98 21 22 32 TB5 (ACS Mode connection) TB7 (Terminal Mode connection) telephone network, public switched Terminal Mode thermal rate of rise thermistor Timer, Auto-silence Timer, Silence Inhibit 11 15 transformer AFP-100/AFP-100E Instruction PN 51010:C1 02/06/2002 Technical Manuals Online! - http://www.tech-man.com...

  • Page 99: Limited Warranty

    Limited Warranty NOTIFIER® warrants its products to be free from defects in materials and workmanship for eighteen (18) months from the date of manufacture, under normal use and service. Products are date stamped at time of manufacture. The sole and exclusive obligation of NOTIFIER® is to...
  • Page 100 World Headquarters NOTIFIER is an operation of 12 Clintonville Road Northford, CT 06472-1653 USA 203-484-7161 fax 203-484-7118 www.notifier.com Technical Manuals Online! - http://www.tech-man.com...
