Voice Alarm Multiplex Manual Number 15889,
Document Divider Information .................................................................................. page 2
Replace the following pages dated 12/11/97, with the same numbered pages dated 10/01/01:
• Cover page/Precautions and Limitations p.1
• Page 19/20
• Page 21/22
• Page 51/52
• Limited Warranty/Rear Cover
Replace Page 3/4 with Precautions and Limitations p.2/Page 4
Supplement to the
AM2020/AFP1010
Revision F1, dated 12/11/97
This supplement includes the following:
Document 15889SUP
F
2
10/01/01 Revision
ECN 01-537
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Notifier AM2020
Summary of Contents for Notifier AM2020
- Page 1 Supplement to the AM2020/AFP1010 Voice Alarm Multiplex Manual Number 15889, Revision F1, dated 12/11/97 This supplement includes the following: Document Divider Information .................. page 2 Replace the following pages dated 12/11/97, with the same numbered pages dated 10/01/01: • Cover page/Precautions and Limitations p.1 •...
- Page 2 Tab Set 50022, Bank 2 for Document 15889 The three-ring binder tab set shown above is shipped with every AM2020/AFP1010 system. If you cannot locate the set in your shipment or if it has been misplaced, you may order another tab set, Part Number 50022, from your Notifier Customer Service Representative.
- Page 3 P/N 15889:F2 ECN 01-537 AM2020/AFP1010 Voice Alarm Multiplex Operation and Installation Manual Document 15889 10/01/01 Rev:...
-
Page 4: Fire Alarm System Limitations
Fire Alarm System Limitations While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance! An automatic fire alarm system—typically made up of Heat detectors do not sense particles of combustion and smoke detectors, heat detectors, manual pull stations, audible alarm only when heat on their sensors increases at a predeter- warning devices, and a fire alarm control with remote notifica- mined rate or reaches a predetermined level. -
Page 5: Installation Precautions
Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be Like all solid state electronic devices, this system may connected to the fire alarm control panel. Disconnect all operate erratically or can be damaged when subjected to light- sources of power before servicing. - Page 6 Figure 3-2 AMG-1 Terminal Connections ....................... 18 Table 3-1 AMG-1 Tone/Message Functions ....................21 Table 3-2 AMG-1 Tone/Message Functions ....................22 Section 3.2 Zone-Coded Voice for the AM2020/AFP1010 ................23 Section 3.3 ATG-2 Audio Tone Generator ...................... 26 Figure 3-3A ATG-2 Terminal Connections ...................... 27 Figure 3-3B ATG-2 Activation Circuit ......................
- Page 7 AM2020 AMG Programming During programming of the AM2020/AFP1010 (and after the installation of any AMG-1s), each AMG-1 must be programmed as if they were annunciators. The address is set on the AMG-1 (25-32) and must correspond to the programmed annunciator address.
- Page 8 This allows the AMG-1 functions to assume the first four points on an ACM-16AT set to address "1." Up to eight AMG-1s may be installed in an AM2020/AFP1010 system. For AMG-1s set in the address range A29-A32:...
- Page 9 Table 3-1: AMG-1 Tone/Message Functions (for AMG-1 addresses A32 through A29) Audio Message Annunciator Control Points Generator DIP on ACM-16AT Address A01 Tone/Voice Message Group Functions Switch Settings AMG-1 at Address VROM A VROM B VRAM A VRAM B 3 Fast Whoops, Pause, VROM A 3 Hi/Low Tones, Pause, VROM B 3 Yeows, Pause, VRAM A 3 Slow Whoops, Pause, VRAM B...
- Page 10 Table 3-2: AMG-1 Tone/Message Functions (for AMG-1 addresses A28 through A25, AMG-X4 EPROM required) Audio Message Annunciator Control Points Generator DIP on AEM-16AT Address A01 Tone/Voice Message Group Functions Switch Settings AMG-1 at Address VROM A VROM B VRAM A VRAM B 3 Fast Whoops, Pause, VROM A 3 Hi/Low Tones, Pause, VROM B...
- Page 11 Voice Alarm Multiplex 15889:F2 10/01/01...
- Page 12 Notes Voice Alarm Multiplex 15889:F2 10/01/01...
-
Page 13: Limited Warranty
NOTIFIER is to repair or replace, at its option, free of charge for parts and labor, any part which is defective in materials or workmanship under normal use and service. For products not under NOTIFIER ® manufacturing date-stamp control, the warranty is eighteen (18) months from date of original ®... - Page 14 World Headquarters One Fire-Lite Place, Northford, CT 06472-1653 USA 203-484-7161 • Fax 203-484-7118 www.notifier.com...
