Media
Compartment
Print Mechanism
Long Side Door
Intermec EasyCoder F2 – Installation & Operation IPL Version, Ed. 1
The media compartment is either covered by a long side door that
completely encloses the print mechanism and media compartment,
or a short side door that only covers the print mechanism and gives
easy access to the media stock. The door is held by a magnetic
lock. It can be opened 180° so to provide full access to the media
compartment.
The media supply can be from a supply post, or from an external
supply of fan folds behind the printer. There is also an optional
rotating media supply hub, see Chapter 8 "Options."
Chapter 2 Installation
Media Supply
Roll Post
with Edge Guide
Optional Integral Liner
Takeup with Guide Shaft
11
