Media Compartment

Description
Print Mechanism
Long Side Door
Intermec EasyCoder F2 – User's Guide
The media compartment is either covered by a long side door
that completely encloses the print mechanism and media com-
partment, or a short side door that only covers the print
mechanism and gives easy access to the media stock. The door is
held by a magnetic lock. It can be opened 180° to provide full
access to the media compartment.
The media supply can be from a supply post, or from an external
supply of fan folds behind the printer. There is also an optional
rotating media supply hub.
Also see Chapter 8, "Options."
Chapter 2
Optional Integral Liner
Takeup with Guide Shaft
Installation
Media Supply
Roll Post
with Edge Guide
11
