Media Compartment
Intermec EasyCoder 501 XP – User's Guide
The media compartment becomes accessible when the right-hand
door is opened. The door is held by a magnetic lock and can be
opened 180°, or be removed completely by pushing it rearwards.
Slack Absorber
Refer to Chapter 9 "Options" for information on possible optional
devices fi tted inside the printer's media compartment.
Ribbon Rewind Hub
Ribbon Supply Hub
Chapter 2
Installation
Media Supply Hub
11
