Operating the 4x1 Multiview Seamless Switcher for HDMI
Chapter
Using the IR Extender
There may be situations where the IR sensor is blocked by a cabinet or other mounting
device. In this case, the included IR extender (Gefen part no. EXT-RMT-EXTIRN) can be
connected to the IR Ext port on the 4x1 Multiview Seamless Switcher. The sensor on the
IR extender behaves exactly like the sensor on the front panel of the switcher. Always point
the IR remote control unit in the direction of the IR sensor.
IR extender
IR remote
IR sensor
page | 32
