Page 1: Matrix Switcher
Gefen 3GSDI Audio Embedder Matrix Switcher Keyboard Controller User Manual Windows • Mac OS Release A1... - Page 2 Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacific Time Gefen Matrix Switcher Keyboard Controller is a trademark of Gefen, LLC. Important Notice Gefen, LLC reserves the right to make changes in this documentation without prior written notice.
- Page 3 Gefen Matrix Switcher Keyboard Controller Operating Notes • If using the Mac OS platform, go to Preferences > Accessibility and make sure that “Enable access for assistive devices” is enabled.
-
Page 4: Table Of Contents
3GSDI Audio Embedder Gefen Matrix Switcher Keyboard Controller Table of Contents Getting Started Installing the Software ................... 2 Windows Installation ..................2 Mac OS Installation ..................6 Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation ....................10 Connecting to a Matrix or Switcher ............. 10 Setting Timeouts .................. -
Page 7: 01 Getting Started
Gefen Matrix Switcher Keyboard Controller 01 Getting Started Installing the Software ................... 2 Windows Installation ..................2 Mac OS Installation ..................6... -
Page 8: Installing The Software
Gefen that allows a computer keyboard to be used to switch between sources. This application uses the Telnet protocol to control any Gefen switcher or matrix that uses IP control. To control any Gefen switcher or matrix, set the correct IP address and send the desired commands using the computer keyboard. - Page 9 Getting Started Installing the Gefen Matrix Switcher Keyboard Controller The Welcome dialog box will be displayed. Click the Next button. The Software License Agreement dialog will be displayed. Click the radio button next to I accept the agreement, then click the Next button.
- Page 10 Getting Started Installing the Gefen Matrix Switcher Keyboard Controller The Select Additional Tasks dialog will be displayed. By default, the Create a deskop icon check box is selected. If a desktop icon is not desired, check this box to deselect this task.
- Page 11 The Launch Gefen Matrix Switcher Keyboard Controller check box will be checked. To launch the Gefen Discovery Tool, click the Finish button. To launch the application at a later time, click the Launch Gefen Matrix Switcher Keyboard Controller check box to remove the check mark, then click the Finish button.
-
Page 12: Mac Os Installation
Getting Started Installing the Gefen Matrix Switcher Keyboard Controller Mac OS Installation Download the Setup_GefMatrixSwitcherKC_v13.zip file from the Gefen Web site. Double-click the .zip file to extract the files to the Desktop. There will be three files within the folder: Setup_GefMatrixSwitcherKC_v13.exe.exe... -
Page 13: Keyboard Controller
Drag-and-drop the GefMatrixSwitcherKC application to the desired location on the Mac. Double-click on the GefMatrixSwitcherKC icon to launch the Gefen Matrix Switcher Keyboard Controller application: Refer to the next section for information on operating the Gefen Matrix Switcher Keyboard Controller. page | 7... -
Page 15: Operating The Gefen Matrix Switcher Keyboard Controller
Gefen Matrix Switcher Keyboard Controller 02 Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation ....................10 Connecting to a Matrix or Switcher ............. 10 Setting Timeouts ..................15 Minimizing / Restoring the Dialog (Windows only) ........16 Terminating the Application (Windows only) ..........16... -
Page 16: Basic Operation
The following examples are taken from the PC platform. Connecting to a Matrix or Switcher Launch the Gefen Matrix Switcher Keyboard Controller from the Start Menu or using the shortcut from the Windows® Desktop. After a few seconds, the Gefen Matrix Switcher Keyboard Controller interface will be displayed. - Page 17 Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation Click the Select Product drop-down list, at the top left of the interface, to select the product that is connected to the computer running the Keyboard Controller software. The following Gefen products are supported: •...
- Page 18 Enter the Telnet listening port in the Port field. The default port is 23. The next step is only required if a user name and password are used to access the Gefen product over a network. If the Gefen product is not configured to ask for login credentials, then skip to step 8.
- Page 19 Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation Select the key to be used as the “routing key” from the Routing Sequence Key drop-down list. Currently, Num Lock is selected. For this example, we will select the Left Ctrl key.
- Page 20 Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation 10. Click the button to confirm the current settings. 11. The “Changes saved Successfully” message will appear at the bottom of the dialog. 12. Near the bottom of the dialog, under the Setup tab, is a sample keystroke sequence: In order to switch Input 3 to Output 5, press and release the CTRL key, twice, on the left side of the keyboard.
-
Page 21: Setting Timeouts
Operating the Gefen Matrix Switcher Keyboard Controller Basic Operation Setting Timeouts Click the Advanced tab, near the top of the dialog. Change the time (in milliseconds) for the key sequence in the Keys Sequence Timeout field, if necessary. By default, the Keys Sequence Timeout is 1000 milliseconds (1 second). If the time interval between keystrokes exceeds 1 second, then the key sequence will not be sent. -
Page 22: Minimizing / Restoring The Dialog (Windows Only)
Click the OK button. The application will still function but is now hidden in the System Tray. To restore the dialog, go to the System Tray, right click the Gefen icon to display the context menu, then select Restore. Terminating the Application (Windows only) Follow the instructions, above, for minimizing the application. - Page 24 Stretch it. Switch it. Split it. Gefen’s got it. ® 20600 Nordhoff St., Chatsworth CA 91311 1-800-545-6900 818-772-9100 fax: 818-772-9120 www.gefen.com support@gefen.com...
