Getting Started Introduction

Panel Layout

ID Name
1 Input Indicators
2 Window Buttons
3 Window Presets
4 Menu System Controls
5 IR
6 Lock
7 Standby LED Indicator
8 Power

Front

1
2
page | 2
3 4
Description
These LED indicators display the state of
each input. See Window Basics
information.
Press these buttons to display up to four
windows on a single display.
Use these buttons to select the desired
window configuration. Five default presets
and 5 user-definable window presets are
available. See Window Basics
information.
Use these buttons to select and change
settings within the built-in menu system.
See Menu System for details.
This IR sensor receives signals from the
included IR remote control unit.
Use this button to lock the 4x1 Multiview
Seamless Switcher and prevent accidental
changes. See Locking / Unlocking the
Switcher for more information on this
feature.
This LED will remain illuminated when
the 4x1 Multiview Seamless Switcher is
powered OFF.
This button is used to power ON and power
OFF the 4x1 Multiview Seamless Switcher.
This button will remain illuminated while the
switcher is powered ON.
6 8
5 7
for more
for more
