Advanced Operation Chapter
The Web interface is divided into seven pages: Routing, I/O Setup, Window Setup,
Presets, EDID, Network, and System. Each main page is represented by a tab at the
top of the screen. The EDID page has its own set of sub-tabs. Click on the desired tab
to open the desired page.
NOTE: In order to view all seven tabs at the top of the screen,
the user must be logged in as "Administrator". If logged-in as
"Operator", only the Routing tab will be visible.
Power
Click this button to toggle the power state of the 4x1 Multiview Seamless
Switcher. When the switcher is powered-on, the button will read "STANDBY".
? Help
Click the "? Help" button to display context-sensitive help. This button is
available on all pages.
Log Out
Click Log Out to terminate the current Web session are return to the login page.

Routing

page | 134
Web Interface
