Gefen Multiview EXT-HD-MVSL-441 User Manual page 15

Getting Started Chapter
ID Name
3 Menu
4 ◄ /►/▲/▼/OK
5 Exit
6 Default Presets
7 User Presets
8 In (1 - 4)
9 Power
10 Window (1 - 4)
11 Lock
12 Mute
13 Rotate
14 Mirror
Description
Press this button to display the built-in
menu system.
Used to access and change features within
the menu system. Use the arrow buttons
to move around within the menu system or
change a value. Press the OK button to
make a selection within the menu system.
Press this button to exit the main menu or
exit from sub-menus.
Use these button to select the desired
window configuration. See
Basics for information on selecting window
configurations.
These buttons are used to store custom
window configuration presets. See
Basics for more information.
Use this buttons to select the input.
Press this button to power-ON or power-OFF
the Multiview Seamless Switcher.
Use these buttons to select the desired
window. Each of these buttons is
associated with the buttons on the front
panel (Window A - D). See
for more information on working with
windows and inputs.
Press this button to lock or unlock the 4x1
Multiview Seamless Switcher.
Mutes the audio on all outputs.
This feature will be available in a future
release of firmware.
Applies a horizontal transformation (rotated
180° about the y-axis) to window output A.
page | 5
IR Remote Control Unit
Window
Window
Window Basics
