Locking / Unlocking the Switcher

Locking the switcher will prevent any changes by disabling all buttons (except the Lock
button) on the front panel. This feature is useful in preventing routing or other changes
caused by accidentally bumping or pressing the buttons on the front panel.
1. Press and hold the Lock button on the front panel. The Lock button will begin to
flash.
2. Continue holding down the Lock button until it stops flashing.
3. The switcher is now locked. The Lock button will remain illuminated as long as the
switcher is locked.
4. To unlock the switcher, press and hold the Lock button. The Lock button will begin to
flash.
5. Continue holding down the Lock button until it stops flashing.
6. The switcher is now unlocked and can be used normally.
Once the switcher is unlocked, the Lock button will no longer be illuminated.
Using the Front Panel Buttons
Switcher is locked
Switcher is unlocked
