Operating the 4x1 Multiview Seamless Switcher for HDMI
Use the ▲ or ▼ buttons to highlight the Minimum R option.
6.
7. Press the Select button to select the Minimum R option. The currently selected
value will be highlighted in orange.
C H R O M A K E Y
M I N I M U M
M A X I M U M
M I N I M U M
M A X I M U M
M I N I M U M
M A X I M U M
C H R O M A K E Y
R E S TO R E D E FA U LT S
B A C K
E X I T
8. Use the ◄ or ► buttons to change the current value.
9. Press the Select button to accept the current changes. If using the IR
remote, press the OK button.
10. Repeat this process for each of the Maximum and Minimum R, G, and B values.
11. Highlight and select the Chroma Key option
12. Use the ◄ or ► buttons to turn chroma keying On or Off.
C H R O M A K E Y
M I N I M U M
M A X I M U M
M I N I M U M
M A X I M U M
M I N I M U M
M A X I M U M
C H R O M A K E Y
R E S TO R E D E FA U LT S
B A C K
E X I T
13. Press the Select button to accept the current changes. If using the IR
remote, press the OK button.
R 0 0 0
R 2 5 5
G 0 0 0
G 2 5 5
B 0 0 0
B 2 5 5
O F F
R 0 0 0
R 0 6 4
G 0 4 8
G 1 2 8
B 0 6 4
B 1 2 8
O N
page | 56
Menu System
