Operating the 4x1 Multiview Seamless Switcher for HDMI
The OSD Settings menu controls how the OSD is displayed.
1. Press the Menu button on the front panel or on the IR remote control. The menu
system will be displayed.
M A I N M E N U
I / O S E T U P
W I N D O W
N E T W O R K
S Y S T E M
E X I T
2. Press the Select button. If using the IR remote, press the OK button.
3. Use the ▲ or ▼ buttons to highlight OSD Settings.
O S D S E T T I N G S
I N F O D I S P L AY
H O F F S E T
V O F F S E T
T I M E O U T
S Y S T E M
E X I T
4. Once the desired option is highlighted, press the Select button to select it. If using the
IR remote control, press the OK button.
When an option is selected, its current value will be highlighted in orange.
O S D S E T T I N G S
I N F O D I S P L AY
H O F F S E T
V O F F S E T
T I M E O U T
S Y S T E M
E X I T

OSD Settings

O N
0 5
0 5
O F F
O N
0 5
0 5
O F F
page | 46
Menu System
