Getting Started Chapter
1 2
ID Name
1 IR Ext
2 In (1 - 4)
3 HDMI Out
4 IP Cont.
5 USB
6 RS-232
7 12V DC

Back

3 4 6
5
Description
Connect the included IR Extender (Gefen
part no. EXT-RMT-EXTIRN) to this port.
Connect up to four Hi-Def sources to these
inputs using HDMI cables.
Connect an HDMI cable from this port to an
HD display.
Connect an Ethernet cable between
this jack and a LAN to use IP control.
Refer to RS-232 and IP Configuration
more information on setting up IP control.
Used for upgrading the firmware.
See Upgrading the Firmware
information.
Connect an RS-232 cable from this port
to an RS-232 device. See
IP Configuration
setting up RS-232 control.
Connect the included 12V DC power
supply from this power receptacle to an
available AC electrical outlet. Do not
overtighten the locking connector on the
power receptacle.
page | 3
Panel Layout
7
for more
RS-232 and
for more information on
for
