Edid ► Assign - Gefen Multiview EXT-HD-MVSL-441 User Manual

Advanced Operation Chapter
If the Lock EDID button is clicked (enabled), the "EDID locked on power cycle"
message will be displayed in red. The local EDID information will now be
locked once the switcher is rebooted. Click the Unlock EDID button to disable
the Lock EDID feature.
Copy EDID From
Select the EDID from the drop-down list. The EDID will be copied from the
Output or selected EDID bank to the destination
Options
Bank 1 ... Bank 8
A - Output 1
EDID ► Assign
Lock EDID
Secures the Local EDID and disables automatic
EDID loading during power-up.
page | 149
Web Interface
