Operating the 4x1 Multiview Seamless Switcher for HDMI Chapter
2. The numbers in each of the colored boxes, below, represent the currently select input
for each Window. Since Input 3 has already been routed to Window C, the source
connected to Input 3 will be displayed:
Input 1
Output
1. Press the button for Window B on the front panel to select it.
2. Press the button for Window B again to select Input 3.
If using the IR remote control, press the Window 2 button, then press the In 3 button.
3. Input 3 has now been routed to Window B. Since Window B is the active output,
the source connected to Input 3 will be displayed:
Note that the Window name is the same. The only difference is that the input has
changed.
Input 2
Window C is displayed
Method 2:
page | 18
Window Basics
Input 3 Input 4
