Chroma Key - Gefen Multiview EXT-HD-MVSL-441 User Manual

Operating the 4x1 Multiview Seamless Switcher for HDMI
See Using Chroma Key
1. Press the Menu button on the front panel or on the IR remote control. The menu
system will be displayed.
M A I N M E N U
I / O S E T U P
W I N D O W
N E T W O R K
S Y S T E M
E X I T
2. Use the ▲ or ▼ buttons to highlight Window.
3. Press the Select button to display the Window Settings menu. If using the IR
remote, press the OK button.
W I N D O W S E T T I N G S
W I N D O W A D J U S T
W I N D O W C O N V E RT
C H R O M A K E Y
B A C K
E X I T
4. Use the ▲ or ▼ buttons to highlight Chroma Key.
5. Press the Select button to display the Chroma Key menu. If using the IR
remote, press the OK button.
C H R O M A K E Y
M I N U M U M
M A X I M U M
M I N I M U M
M A X I M U M
M I N I M U M
M A X I M U M
C H R O M A K E Y
R E S TO R E D E FA U LT S
B A C K
E X I T

Chroma Key

for more information about the chroma key process.
R 0 0 0
R 2 5 5
G 0 0 0
G 2 5 5
B 0 0 0
B 2 5 5
O F F
