Gefen Multiview EXT-HD-MVSL-441 User Manual page 6

4x1 Multiview Seamless Switcher for HDMI 3GSDI Audio Embedder
Features and Packing List
• Seamless switcher with 4 inputs
• Adjustable scaling and resizing of each input
• Display up to 4 windows on a single display
• Input and Output resolutions up to 1080p Full HD and 1920x1200 (WUXGA)
• HDCP compliant
• Seamless switching ensures no switching delay and no picture loss during transitions
• Default pre-configured Multiview window arrangements can be accessed via five front
panel preset push-buttons
• Custom user-configurable Multiview window layouts can be accessed via five front
panel preset push-buttons
• User-selectable playback of HDMI audio content from any of the four inputs
• Controllable via front panel controls, IR, IP (web server interface, Telnet, and UDP),
and RS-232
• Easy to use on-screen Graphical User Interface (GUI) and web server interface
• Handheld IR remote control and IR Extender input on back panel
• Field-upgradable firmware via web server interface
• USB port (reserved for future product enhancements)
• Locking power supply connector
• 1U tall rack-mountable enclosure, rack ears included
Features
1080P
®
vi
