Operating the 4x1 Multiview Seamless Switcher for HDMI
Use the ▲ or ▼ buttons to highlight the option to change. The Mode option will be
5.
highlighted, automatically.
6. Once the desired option is highlighted, press the Select button to select it. If using the
IR remote control, press the OK button.
When an option is selected, its current value will be highlighted in orange.
I P S E T T I N G S
M O D E
S TAT I C S E T
B Y T E 1 H I G H
B Y T E 2
B Y T E 3
B Y T E 4 L O W
H T T P P O RT
R E - L I N K
R E S TO R E D E FA U LT S
B A C K
E X I T
S TAT I C I P N O T L I N K E D
7. Use the ◄ or ► buttons to change the current value.
8. Press the Select button to accept the current changes. If using the IR remote control,
press the OK button.
Set this option to either Static or DHCP. If using the Static option, the IP address must be
specified. Use the Byte 1 High , Byte 2, Byte 3, and Byte 4 Low options to set each of the
digits in the IP address, subnet mask, and gateway.
Use this option to switch between the IP address (IP), subnet mask (Mask), and gateway
(Gate).
Use the Byte 1 High, Byte 2, Byte 3, and Byte 4 Low options to set each of the digits in the
IP address, subnet mask, and gateway.
Sets the HTTP listening port for the 4x1 Multiview Seamless Switcher for HDMI.
S TAT I C
I P
1 9 2
1 6 8
0 0 1
0 7 2
0 7 2
N o
Mode
Static Set
Byte
HTTP Port
