Window Priority - Gefen Multiview EXT-HD-MVSL-441 User Manual

Operating the 4x1 Multiview Seamless Switcher for HDMI Chapter
The built-in Web interface allows windows to be resized and arranged in any order.
Windows can also be placed above or below one another. The ordering of overlapping
objects in two-dimensional space is sometimes referred to as the z-order.
Priority = 4
Window on bottom
NOTE: Window B is always set to priority 1 and cannot be changed.
Refer to
In the illustration above, the red window is set to priority 1 and will be displayed on top of
all other windows. Setting a window to priority 4 (the blue window) will move the window
to the bottom-most position. The smaller the number, the higher priority. Multiple windows
cannot share the same priority.
Note that the 4x1 Multiview Seamless Switcher for HDMI does not allow a window to
have a transparency property. This is only used by the diagram, above, to illustrate how
windows can be placed behind or in front or one another.

Window Priority

4
3
2
1
Single Window Nomenclature
page | 24
y-axis
Priority = 1
Window on top
z-axis
for more information.
Window Basics
x-axis
