Advanced Operation Chapter
The 4x1 Multiview Seamless Switcher for HDMI supports IP-based control using Telnet,
UDP, or the built-in Web-based GUI. To set up IP control, the network settings for the
4x1 Multiview Seamless Switcher for HDMI must be configured via RS-232. The default
network settings for the 4x1 Multiview Seamless Switcher are as follows:
Description
IP Address
Subnet
Gateway
HTTP Port
1. Connect an RS-232 cable from the PC to the 4x1 Multiview Seamless Switcher for
HDMI. Also make sure that an Ethernet cable is connected between the 4x1 Multiview
Seamless Switcher and the network.
2. Launch a terminal emulation program (e.g. HyperTerminal) and use the RS-232
settings listed on the previous page.
NOTE: Depending upon the network, all related IP, Telnet, and
UDP settings will need to be assigned. Consult your network
administrator to obtain the proper settings.
3. Set the IP address for the 4x1 Multiview Seamless Switcher using the
command.
4. Set the subnet mask using the
5. Set the gateway (router) IP address using the
6. Set the Telnet listening port using the
7. Set the HTTP listening port using the
8. Set the UDP remote IP address for the switcher using the
command.
9. Set the UDP listening port for the switcher using the
10. Set the UDP remote port for the switcher using the
command.
11. Reboot the switcher to apply all changes, then type the IP address that was
specified in step 3, in a Web browser to access the Web GUI. Use the same IP
address to Telnet to the switcher.

IP / UDP Configuration

IP Address / Port
192.168.1.72
255.255.255.0
192.168.1.254
80
#set_netmask
page | 69
RS-232 and IP Configuration
Description
UDP Port
Local UDP Port
Remote UDP IP
Remote UDP Port 50008
command.
#set_gateway
#set_telnet_port
#set_http_port command.
#set_udp_remote_ip
#set_udp_port
#set_udp_remote_port
IP Address / Port
23
50007
192.168.1.255
#set_ipadd
command.
command.
command.
