Operating the 4x1 Multiview Seamless Switcher for HDMI Chapter

Video Effects

NOTE: Video effects are only applicable to single-window
applications. Multiple-window effects are not supported.
When using single windows, the 4x1 Multiview Seamless Switcher for HDMI provides three
unique post-production video effects: Fade, Chroma Key, and Mirror.
The fade effect applies a one-second cross-dissolve transition when switching between
windows that are receiving video from different sources. This feature, as with all video
effects, is only available when viewing a single window output.
0 sec
1. Access the Web interface for the 4x1 Multiview Seamless Switcher for HDMI.
See the section
2. Selecting the Routing tab.
Click the radio button next to the Default 1 preset.
3.
4. Click to place a check mark in the Fade check box.
5. To see the fade effect, switch between outputs using the IR remote control or the
window buttons on the front panel.

Using Fade

Web Interface for more information.
page | 26
1 sec
