Gefen Multiview EXT-HD-MVSL-441 User Manual page 60

Operating the 4x1 Multiview Seamless Switcher for HDMI
Press the Select button to select the Lock EDID option.
5.
6. Use the ◄ or ► buttons to change the value of the Lock EDID option.
7. Press the Select button to accept the Lock EDID value.
E D I D
L O C K E D I D
C O P Y TO A L L
O U T P U T
1 0 8 0 P 2 C H
1 0 8 0 P M U LT I
B A C K
E X I T
1. Make sure the Lock EDID option is set to No.
2. Use the ▲ or ▼ buttons to highlight the desired output, containing the EDID to be
copied to the input. The 1080p 2 Ch or 1080p Multi Ch EDID can also be selected.
When selecting an EDID, make sure that all displays can support the same audio
and video capabilities
3. Press the Select button to accept the current output selection. If using the IR remote,
press the OK button.
E D I D
L O C K E D I D
C O P Y TO A L L
O U T P U T
1 0 8 0 P 2 C H
1 0 8 0 P M U LT I
B A C K
E X I T
4. The display will flash momentarily. The EDID from the selected output will be copied
to the input and will be used by all outputs.
Ye s
I N P U T S
C O P Y
C O P Y
C O P Y
Selecting an EDID
N o
I N P U T S
C O P Y
C O P Y
C O P Y
page | 50
Menu System
