Operating the 4x1 Multiview Seamless Switcher for HDMI Chapter
Use the ▲ or ▼ buttons to highlight the desired output resolution.
5.
O U T P U T R E S O L U T I O N
4 8 0 P
5 7 6 P
7 2 0 P 5 0
7 2 0 P 6 0
1 0 8 0 p 2 4
1 0 8 0 p 5 0
1 0 8 0 p 6 0
1 0 2 4 x 7 6 8
1 2 8 0 x 8 0 0
1 2 8 0 x 1 0 2 4
1 3 6 6 x 7 6 8
1 4 4 0 x 9 0 0
1 6 0 0 x 9 0 0
1 6 0 0 x 1 2 0 0
1 6 8 0 x 1 0 5 0
1 9 2 0 x 1 2 0 0
N AT I V E
B A C K
E X I T
6. Press the Select button to apply the highlighted resolution. If using the IR remote,
press the OK button.
If the display does not support the selected resolution, use the
command to reset the 4x1 Multiview Seamless Switcher for HDMI.
See RS-232 and IP Configuration for more information on commands.
page | 37
Menu System
