Service Instructions Dishwashing Machine Model K-Tronic

8 Error indication, Information and Instructions

8.1 Error indication, no wash process possible

Err.
Display
No.
External EEPROM
1
Internal EEPROM
2
3 System error SW
4 EEPROM language
5 I/O-board defective
8 Program-number not
defined
101 Emergency stop act.
Timeout on filling
201
Refill error
202
Conveyor overload
701
Datei: 2K_9628652_Serviceanleitung-MIKE_EN_2005-09-01.doc
MEIKO Maschinenbau GmbH & Co. KG, Postfach 2040, D-77652 Offenburg, Tel.: +49/781/203-0, Fax: +49/781/203-1174
Note / Possible causes
System
EEPROM not available, no data
Hardware defect; change CPU circuit
board
Download language set
Software system error or electromagnetic
compatibility problems
Defect or damp in the membrane key-
pad
Hardware defect
RAM, ROM, PROG test defective;
Wash program (speed etc.) not defined
General information
Emergency stop switch has been
activated
Tank
Set level in tank not reached at right time
(P307);
Water supply from the mains inadequate;
Inlet valve does not open (correctly)
mechanical / electrical;
Cable broken in wiring to the valve;
Level sensor defective
Set level in tanks not reached at right
time (P307);
Water supply from the mains inadequate;
Inlet valve does not open (correctly)
mechanical / electrical;
Cable broken in wiring to the valve;
Level sensor defective
Conveyor system
Blockage
Motor protection switch triggered
Overload detected
Frequency converter
valid from: 2005-09-01 Update: 2006-11-14 / S.5

W e reserve the right to change execution and construction!

Possible measures
Plug in EEPROM or re-define
(download with M-
Commander)
Change CPU circuit board
Download language set.
Test with a new membrane
key-pad
Change input/output circuit
board
Replacing I/O circuit boards in
succession
Allocate an available program
to the key (see parameter
P104 - P106)
Release the emergency stop
Float hanging,
check tank circuit board
position
Remove blockage,
(reverse conveyor if
necessary).
Measure voltage / power
consumption.
Adjust overload system.
Check parameters.
Page 21/30
Ident No.: 9627429
