Section FUNCTIONAL SUMMARY

System Status Register 1

Bits
3-0
5-4
7-6
6
The PT-VME161 does not support SRAM so this field is always read as zero. This provides backwards compati-
bility with the PT-VME151.
64 Extensible Single Board Computer/Controller User's Manual
Address 0C000000h
Byte Read Only
7 6 5 4 3
Name Function
HSW Value of Hex Switch
SRSZ SRAM Size
0 No SRAM installed
Reserved, mask to zero when read
2 1 0
HSW[3-0]
SRSZ[1-0]
Reserved
