Performance Computer
All Jumper Blocks are designed to mate with standard 2 pin jumper shunts. Spare jumper shunts can be stored
by slipping one side of the jumper shunt on a single, unused pin of a jumper block and allowing the other side
of the jumper shunt to hang in space. As shown at left:
Extensible Single Board Computer/Controller User's Manual 13
