Hardware Configuration; Device Positions; Figure 1: Pt-Vme161 Device Positions - Performance Computer PT-VME161 User Manual

2
Section GETTING STARTED

Hardware Configuration

A layout for the PT-VME161 is shown in "Figure 1: PT-VME161 Device Positions". The model
PT-VME161 and PT-VME161E are two versions of the same PCB with different component options.
There are various jumpers to configure user options which must be set before initial bootup. Refer to the
information in this section to verify that you have the correct settings.

Device Positions

K1
K3
K10
K4
K11
Serial
No.
K8
K9
12 Extensible Single Board Computer/Controller User's Manual

Figure 1: PT-VME161 Device Positions

K2
Note Orientation
Note Orientation
TERM
Assy
Rev
Label
U24
Caution:
U36
Caution:
F1
K6
K7
SCSI
K13
K12
K5
