DMA Mechanism

SCSI data phase bytes can be transferred with Direct Memory Access of the PT-VME161. Under
program control the following steps must be performed to initiate a SCSI DMA transfer:
The SCSI Memory Address Register must be loaded with the source/destination address for the
transfer.
The System Control Register, SCSI DMA Read/Write Direction (SCDRD) bit is written to indicate
to the PT-VME161 control logic the direction of the transfer.
The FAS216 Transfer Count register is loaded with the desired size of the transfer (up to 64 KBytes).
Issue a data transfer command to the FAS216.
The hardware will handle the data transfer between the FAS216 and local DRAM.
Parity is generated and checked by PT-VME161 hardware on local DRAM Accesses during SCSI DMA.
A level 7 interrrupt may be generated if a parity error is detected. See "Parity" on page 30 for more infor-
mation.

Interrupts

The 68060 can be notified of the completion of an operation of a change in state through the interrupt
mechanism provided on the FAS216 and SCV64. The FAS216 Interrupt Register, in conjunction with
the FAS216 Status and FAS216 Sequence Step registers, are used to determine the source of an FAS216
interrupt.
For FAS216 interrupts to be forwarded to the 68060 the SCV64 the interrupt mechanism must be enabled
by setting the L3E bit in the SCV64 Local Interrupt Enable Register. The current state of this signal can
be read in the LI3 status bit of the SCV64 Local Interrupt Status Register. See the VMEbus Interface,
SCV64, General Purpose Local Interrupts, I/O Event, FAS216 Requests section above for further infor-
mation.
NOTE: The SCV64 General Purpose Local Interrupt input is driven by the FAS216 INT or the EPAK
EPIRQ signal!
A second interrupt mechanism exists that allows the detection of a RESET condition on the SCSIbus. A
Level 7 L7IMEM interrupt can be generated in the SCV64. The interrupt is enabled by setting the
MEMIS bit in the SCV64 Level 7 Interrupt Status Register. The current state of this signal can be read
in the MEMIP status bit of the SCV64 Status Register 0. See VMEbus Interface, SCV64, Interrupt
Handler, Local Level 7 Sources section above.
See the FAS216 Technical Manual for more information on the Fast SCSI Processor Chip.

Termination

Fuse F1 (Littelfuse Part No. 273-001) provides short circuit protection for TERMPWR. To remove the
fuse, place the PT-VME161 on a work surface component side up with the VMEbus connectors closest
to the observer. Grip the clear body of fuse F1 and pull to the right. To replace the fuse reverse the
Extensible Single Board Computer/Controller User's Manual 55
