Controls and Indicators
The figure below identifies the controls and indicators that reside on the PT-VME161 Front Panel.
Figure 13: PT-VME161 Front Panel Controls and Indicators
Rotary Switch
A hexadecimal rotary switch is provided for utility input purposes. The switch state is accessible to the
firmware through the System Status Register.
PT-VME
161
"RUN" Indicator
"FAULT" Indicator
"VME" Indicator
RESET Switch
Rotary Switch
ABORT Switch
User Programmable LEDs
Optional EPAK I/O Connector
RS-232 Utility Port
VME64
Performance
Technologies
Extensible Single Board Computer/Controller User's Manual 73
