Dram Module; Table 15: Epak Mounting Standoffs; Table 16: Dram Module Connections - Performance Computer PT-VME161 User Manual

The EPAK mounting standoffs are used to carry power and ground to the EPAK module.

DRAM Module

The DRAM Module standoff carries ground to the module.]

Table 15: EPAK mounting standoffs

Mounting pin
1
2
3
4
5
6

Table 16: DRAM Module Connections

Pin Signal
1 GND
2 D0
3 D1
4 D2
5 D3
6 D4
7 D5
8 D6
9 D7
10 GND
11 WE0
12 GND
13 RAS0
14 A0
15 A1
16 A2
17 MSIZ2
18 MSIZ0
19 GND
20 MSIZ1
21 GND
22 CAS0
Extensible Single Board Computer/Controller User's Manual 79
Performance Computer
Signal
GND
+5V
GND
+5V
GND
GND
Pin Signal
41 GND
42 D8
43 D9
44 D10
45 D11
46 D12
47 D13
48 D14
49 D15
50 GND
51 WE1
52 GND
53 RAS1
54 A6
55 A7
56 A8
57 GND
58 CAS1
59 GND
60 PERR
61 SPARE
62 PARPR
