22 Extensible Single Board Computer/Controller User's Manual
Figure 7: PT-VME161 Front Panel
Captive Chassis Mount Screw
PT-VME
Ejector Handle
161
System Status Indicators
RESET Switch
Rotary Switch
ABORT Switch
User Programmable LEDs
Optional EPAK I/O Connector
RS-232 Utility Port
VME64
Ejector Handle
Performance
Technologies
Captive Chassis Mount Screw
