5
GPS/GPS-A OPERATION
GPS memory operation
■
3. GPS Memory date programming
!2 Push D-pad() to select "DATE."
D-pad
(Ent)
(�)
!3 Push D-pad(Ent), then the editing date screen ap-
pears.
• The edited dates are displayed.
!4 Rotate [DIAL] to edit the date.
• The dates between 2000/01/02 to 2099/12/30 are
programmable.
!5 Push D-pad() to move the cursor left or right to
select and edit the year, month or day.
!6 Repeat steps !4 and !5 to enter a GPS Memory
date.
!7 After entering the date, push D-pad(Ent).
4. GPS Memory time programming
!8 Push D-pad() to select "TIME."
!9 Push D-pad(Ent), then the editing screen appears.
• The edited time is displayed.
@0 Rotate [DIAL] to edit the time.
• The time between 00:00:00 to 23:59:59 are pro-
grammable.
@1 Push D-pad() to move the cursor left or right to
select and edit the hour, minute or second.
@2 Repeat steps @0 and @1 to enter GPS Memory
time.
@3 After entering the time, push D-pad(Ent).
5. GPS Memory latitude programming
@4 Push D-pad() to select "LATITUDE."
@5 Push D-pad(Ent), then the editing screen appears.
@6 Rotate [DIAL] to edit the latitude.
• The latitude between 0°00.00' to 90°00.00' are
programmable.
If "ddd° mm' ss"" is selected in POSITION FOR-
MAT screen, between 0°00'00" to 90°00'00" are
programmable.
(MENU > GPS > GPS Set > Position Format)
@7 Push D-pad() to move the cursor to left or right to
select and edit degrees or decimal minutes.
@8 Repeat steps @6 and @7 to enter a GPS Memory
latitude.
• Select "N" to program the north latitude, and "S"
when program the South latitude.
@9 After entering the latitude, push D-pad(Ent).
(Continued on the next page)
(Continued)
5-10
