Page 1 INSTRUCTION MANUAL 7075 Before copying, read this guide. Keep in the right hand rear pocket of the machine.
Page 2 Thank you very much for your purchase of the Konica 7075. This Manual deals with making copies, correct handling of the machine, and precautions for safety. Please read before copying. In order to maintain a satisfactory copying performance, please keep this Manual readily available for reference in the right hand rear pocket of the machine.
Page 3: Table Of Contents
Introduction Contents Safety Section 1: Introduction Information Features of the Konica 7075 ..................1-2 Copier Features ......................1-7 Machine Standard Equipment ....................1-7 Information Optional Equipment ....................1-7 Section 2 : Safety Information Paper Caution Labels and Indicators ..................2-2 Information Danger, Warning and Caution Symbols ................
Page 4 Contents Section 4: Paper Information Positioning Originals on the Platen Glass ..............4-2 Positioning an Original for Manual Copying ............4-2 Using the Reversing Automatic Document Feeder (RADF) .......... 4-3 Positioning Originals ....................4-4 Positioning an SDF Original ................... 4-4 Positioning Mixed Originals ..................
Page 5 Introduction Contents Safety Section 6: Basic Operations (continued) Information Paper Size ........................6-19 Selecting Paper Type/Size for Multi-sheet Bypass Tray ........6-20 Machine Reserve ........................6-23 Information Set Reserve Job ....................6-23 Job Status Screen ....................6-25 Mishandled Paper During the Reserve Setting ............ 6-27 When Paper is Depleted for the Job in Progress ..........
Page 6 Contents Section 9 : Applications Application Function Menu .................... 9-2 Sheet/Cover Insertion ....................9-3 Chapter ......................... 9-9 Combination ........................ 9-12 Booklet ........................9-15 OHP Interleave ......................9-20 Image Insert ........................ 9-23 Dual Page ........................9-27 Program Job ........................ 9-31 Non-Image Area Erase ....................9-34 Reverse Image ......................
Page 7 Introduction Contents Safety Section 12 : Key Operator Mode (continued) Information User Setting Mode [3] ....................12-12 User Density Level 1 Setting [1] ................. 12-12 Machine User Density Level 2 Setting [2] ................. 12-13 Information User Lens Mode Ratio Setting [3] ..............12-14 E.K.C.
Page 8 Contents Section 14: Troubleshooting Call for Service ......................14-2 Limited Use of the Copier in Trouble ..............14-3 Memory Overflow ......................14-4 Power OFF/ON Screen ....................14-5 Clearing Mishandled Paper ..................14-6 Copying Hints ......................14-8 Section 15: Machine Specifications Main Body Specifications ....................
Page 9: Section 1: Introduction
Introduction Section 1: Introduction Features of the Konica 7075 Copier Features Standard Equipment Optional Equipment...
Page 10: Features Of The Konica 7075
Section 1 : Introduction Features of the Konica 7075 • 600dpi Mode Scan in higher resolution (600dpi) than in normal mode (400dpi). • All-Image Area Make copies printed completely to the edges to avoid image loss. • AE - Automatic Exposure Automatically adjust exposure to compensate for the original.
Page 11 Section 1 : Introduction Introduction Features of the Konica 7075 (continued) • Density Shift Shift each seven density levels of 4 density modes (Auto, Text, Photo, Increase Contrast) into two levels to lighter and three levels to darker. • Dual Page Copy both pages of an open book or book-size sheet separately onto two A4 sheets in 1s1 mode or separately onto each side of one A4 sheet in 1s2 mode.
Page 12 • Non STD Size for Original Identifies the special original size which the 7075 could not detect in order to select the optimal paper size for copying or printing. • OHP Interleave Copy onto OHP film and interleave blank or copied paper for each original copied.
Page 13 (10 ~ 150mm) permits in manual or auto. • Reserve Scan in subsequent copy jobs while the 7075 is busy printing or copying. • Resolution (High, Very High) High resolution mode and Very High resolution mode provide optimal image quality for photos and complicated graphics and text that require high to very high compression amounts.
Page 14 Section 1 : Introduction Features of the Konica 7075 (continued) • Server Function (option) Store image data in the HDD for future printing (or transmit the data to a PC over a network for editing and printing). • SDF Feed thick original one sheet at a time from the document feeder.
Page 15: Copier Features
Section 1 : Introduction Introduction Copier Features Standard Equipment Main Body with 3 Paper Trays (500/500/1,000 sheets) Reversing Automatic Document Feeder (RADF) (DF-313) Automatic Duplex Unit (ADU) Configuration Options: with Multi-Sheet Bypass Tray (150 sheets) Optional Equipment Stapler Finisher (FS-108) This finisher is equipped with two exit trays.
Page 16 Section 1 : Introduction Copier Features (continued) Optional Equipment (continued) Punching Unit (PU-108) Used when selecting PUNCH on the Finisher Mode Selection Screen. Punching / Z-Folding Unit (PZ-108) Used when selecting PUNCH and/or Z-FOLDING on the Finisher Mode Selection Screen. Cover Sheet Feeder (PI-108) Used when selecting COVER SHEET on the Finisher Mode Selection Screen, or when stapling copies manually.
Page 17: Section 2 : Safety Information
Section 2 : Safety Information Safety Information Caution Labels and Indicators Danger, Warning and Caution Symbols Requirements for Safe Use Power Source Environment Precautions for Routine Handling...
Page 18: Caution Labels And Indicators
Section 2 : Safety Information Caution Labels and Indicators The caution labels and indicators are attached to the machine areas, as shown below, where you are advised to pay special attention to avoid any dangerous situations or serious injury. CAUTION Burns or injury may occur from touching the areas detailed in the caution labels and caution indicators.
Page 19 Section 2 : Safety Information Caution Labels and Indicators (continued) Safety Information Tray 1 Tray 2 CAUTION CAUTION DO NOT put your hand between the main body and tray; otherwise you may be injured. Tray 3 (FS-108/108BM) CAUTION Use care after opening the paper exit outlet.
Page 20: Danger, Warning And Caution Symbols
Section 2 : Safety Information Danger, Warning and Caution Symbols The following indicators are used on the caution labels or in this manual to categorize the level of safety cautions. DANGER: Action highly liable to cause a death or serious injury. WARNING: Action liable to cause a death or serious injury.
Page 21: Requirements For Safe Use
Section 2 : Safety Information Requirements for Safe Use Safety Information To ensure your safe use of the machine, the following describes the precautions you are required to observe without fail for the power source of the machine and during installation and routine handling.
Page 22: Environment
Section 2 : Safety Information Requirements for Safe Use (continued) Environment CAUTION: Prevention of Fire Do not install near flammable materials, curtains and volatile combustibles, that can catch or cause fire. CAUTION: Prevention of Short Circuit Do not install the copier where it could be splashed with rain water, or water from a tap, to avoid a short circuit.
Page 23 Especially leave an adequate space behind the machine to let hot air out from the rear fan. (Unit: mm) 1603 1203 1762 1845 Konica 7075 (Unit: mm) 1603 1203 1814 1845 2344 Konica 7075 + FS-108/108BM + LT-401 2 - 7...
Page 24 2829 1845 3599 Konica 7075 + FS-108BM + TU-108 + PU-108/PZ-108 + LT-411 Please Be Reminded! Finisher primary (main) tray of FS-108/FS-108BM Finisher gradually goes down while printed material is output. DO NOT allow any object to interfere with the operation of the tray on the left side of the finisher, as any interference may cause damage to the finisher.
Page 25: Precautions For Routine Handling
Section 2 : Safety Information Requirements for Safe Use (continued) Safety Information Precautions for Routine Handling WARNING: High Voltage DO NOT TOUCH the high voltage parts indicated with WARNING label or described in the manual. CAUTION: Actions in Response to Troubles •...
Page 26 Section 2 : Safety Information Requirements for Safe Use (continued) Precautions for Routine Handling (continued) CAUTION: Recommendation of Periodic Check Be sure to check periodically the following points: (1) The main lead or the power plug does not generate abnormal heat. (2) The power plug is not inserted loosely or the lead is not cut or scratched.
Page 27 Section 2 : Safety Information Requirements for Safe Use (continued) Safety Information Precautions for Routine Handling (continued) Trimmer Unit Tray (FS-108BM with TU-108 only) 512 sheets max. (A3, B4, A4R) (The maximum number of sheets varies, depending on the number of pages in the booklet and whether Folding or Stapling &...
Page 29: Section 3: Machine Information
Section 3: Machine Information Machine Configuration External Machine Items Internal Machine Items Machine Information Optional Equipment Machine Configuration Control Panel Layout Control Panel/ Touch Screen Touch Screen Initial Settings Basic Screen Automatic Settings Initial Settings Automatic Settings Auto/Reset Mode Automatic Paper Selection (APS) Automatic Magnification Selection (AMS) Automatic Exposure (AE) Automatic Tray Switching (ATS)
Page 30: Machine Configuration
Section 3 : Machine Information Machine Configuration External Machine @0 C ontrol panel !9 L CD touch screen qRADF !7 F S-108/108BM wWork table Finisher (option) eMulti-sheet bypass tray rLCT top door !4 P ower switch !3 L eft side cover (not shown) !2 F ront door !0 T ray 1...
Page 31: External Machine Items
Section 3 : Machine Information External Machine Items q RADF (Reversing Automatic Document Feeder) automatically feeds multiple originals one at a time to the platen glass for copying. w Work table provides a convenient workspace for documents both before and after Machine copying.
Page 32: Internal Machine Items
Section 3 : Machine Information Machine Configuration (continued) Internal Machine qToner bottle uReset switch wToner unit yFixing unit eLever A tKnob rDrum unit Internal Machine Items q Toner bottle holds toner and is to be replaced when supplying toner. w Toner unit holds the toner supply. e Lever A can be moved to withdraw the conveyance fixing unit for removal of mishandled paper.
Page 33: Optional Equipment
Section 3 : Machine Information Machine Configuration (continued) Optional Equipment Machine FS-108/108BM Finisher details Information Secondary (sub) tray: Holds sets ejected in Machine Cover sheet feeder (option): q Non-sort Face Down exit mode Configuration Holds cover sheets for use in Cover w Non-sort Face Up exit mode Sheet output mode or a copied set in e Group Face Down exit mode...
Page 34 Section 3 : Machine Information Machine Configuration (continued) Optional Equipment (continued) TU-108 Trimmer unit details FS-108BM Finisher Trimmer stacker cover: opens to allow you to take out the finished sets. Trimmer unit tray: slides to the left side each time a trimmed booklet is delivered.
Page 35 Section 3 : Machine Information Machine Configuration (continued) Optional Equipment (continued) Machine Upper lever: PU-108 Punching unit details Information opens upward to allow removal of Machine Knob: Configuration mishandled paper. can be turned to ease removal of mishandled Right lever: paper.
Page 36: Control Panel Layout
Section 3 : Machine Information Control Panel Layout COPY TIMER SCANNER / SERVER PRINTER INTERRUPT POWER SAVER ON / OFF PROOF COPY CHECK HELP STOP JOB MEMORY AUTO RESET COUNTER CLEAR QTY. START q LCD TOUCH SCREEN displays machine and copying status; help information; interactive screens;...
Page 37: Touch Screen
Control Panel/ scratched. Touch Screen After the power switch is turned on, the Konica name displays for approximately 10 seconds, until initial machine settings are established. Then, the Warm-Up Screen displays for approximately 6 minutes, until the fixing temperature is reached.
Page 38: Initial Settings
Section 3 : Machine Information Initial Settings Initial settings represent the initial condition when power is turned on; when EKC password is set; or when Auto/Reset mode is restored, either manually or automatically. Print Quantity; 1 Magnification Ratio: 1:1 (key operator setting) RADF: ON (key operator setting) Copy mode: 1s1 mode (key operator setting) AE: (Automatic Exposure) : ON (key operator setting)
Page 39: Automatic Settings
Section 3 : Machine Information Automatic Settings Auto/Reset Mode The Auto/Reset function can be set for OFF/ 30 seconds/ 1 minute/ 1.5 minutes/ 2 minutes/ 2.5 minutes/ 3 minutes/ 3.5 minutes/ 4 minutes/ 4.5 minutes/ 5 minutes by the key operator. Machine Machine Initially, the mode is set to function after 1 minute of copier inactivity.
Page 40: Service Settings
DIP switch settings. Contact your service centre if setting change is required. Finisher-Paper Capacity In the default condition, the 7075 will produce unlimited sets. If required, service can set the copier to stop copying when the number of copies exceeds specified capacity. Key Operator Password Service can set a 4-digit Key operator password to access the Key Operator Mode Screen.
Page 41: Section 4: Paper Information
Section 4: Paper Information Positioning Originals on the Platen Glass Positioning an Original for Manual Copying Using the Reversing Automatic Document Feeder (RADF) Positioning Originals Positioning an SDF Original Paper Positioning Mixed Originals Information Paper in Main Body Trays Paper in Large Capacity Tray (LT-401) (Option) Paper in Large Capacity Tray (LT-411) (Option) Paper in Multi-Sheet Bypass Tray Paper in Automatic Duplex Unit...
Page 42 Section 4 : Paper Information Positioning Originals on the Platen Glass Positioning an Original for Manual Copying Use the platen glass when originals are not suitable for use with the document feeder, e.g., when size is incompatible, or when originals are folded, stapled, torn, or in generally poor condition.
Page 43: Using The Reversing Automatic Document Feeder (Radf)
Section 4 : Paper Information Using the Reversing Automatic Document Feeder (RADF) Specifications in 1s1, 1s2, 2s2, 2s1 Copying ❒ Original size range: A3, B4, F4, A4R, A4, B5R, B5, A5R, A5 ❒ Original weight: 50~130g/m (no special stock) ❒ Max. RADF tray capacity: 100 sheets (80g/m paper) ❒...
Page 44: Positioning Originals
Section 4 : Paper Information Using the Reversing Automatic Document Feeder (RADF) (continued) Positioning Originals The document feeder (RADF) automatically feeds up to 100 originals directly to the platen glass, starting with the top sheet. The RADF should only be used for unstapled, unfolded, smooth, flat originals.
Page 45: Positioning Mixed Originals
Section 4 : Paper Information Using the Reversing Automatic Document Feeder (RADF) (continued) Positioning Mixed Originals Mixed size originals can be copied together from the document feeder in either APS mode or AMS mode. In APS mode, copies will be output on mixed paper sizes to match the originals.
Page 46: Paper In Main Body Trays
Section 4 : Paper Information Paper in Main Body Trays Loading Paper Size : Max. 314mm (D) x 445mm (W) ~ Min. 100mm (D) x 148mm (W) STD Size : A3, B4, F4, A4, A4R, B5, B5R, A5, 11"x17", 8.5"x14", 8.5"x11" (user- adjustable) STD Size (Special) : 8.5"x11"R instead of A4R 5.5"x8.5"/5.5"x8.5"R instead of A5/A5R...
Page 47: Paper In Large Capacity Tray (Lt-411) (Option)
• A5 copy paper is available in portrait orientation feeding only. Paper Weight : 60~170g/m Duplex Tray Capacity: Unlimited stackless duplex tray NOTE: Reliability and copy quality are not guaranteed for all Special papers. Use only paper that is recommended by Konica. 4 - 7...
Page 48: Paper In Fs-108/108Bm Finisher (Option)
Section 4 : Paper Information Paper in FS-108/108BM Finisher (Option) FS-108/108BM Finisher accepts A3, B4, F4, A4R, A4, B5R, B5, A5R, A5, B6R and A6R paper sizes. The finisher tray capacities classified according to paper size in each output mode are described below. CAUTION: When the finisher capacity is exceeded due to the print quantity selected, remove the copied sets while the paper is exiting;...
Page 49: Fs-108Bm Finisher Booklet Tray
Section 4 : Paper Information Paper in FS-108/108BM Finisher (Option) (continued) FS-108BM Finisher Booklet Tray Folding mode: STD Size : A3, B4, A4R (11"x17", 8.5"x14", 8.5"x11"R) Wide Size : A3W, B4W, A4WR (11"x17"W, 8.5"x11"WR) Paper Paper Weight : 60~90g/m paper (80g/m paper is recommended) Information Number of Folded Sheet : 3 sheets max.
Page 50: Paper In Punching Unit (Pu-108) (Option)
Section 4 : Paper Information Paper in Punching Unit (PU-108) (Option) Punching mode: Copy Paper Size : A3, B4, A4, B5 Paper Weight : 60~90g/m paper (80g/m paper is recommended) Thick 1; 91~170*g/m paper Thin; 50~59g/m paper *: Some 170g/m paper types may not be punched easily.
Page 51: Paper In Trimmer Unit (Tu-108) (Option)
(One 200g/m sheet only used as a cover) * Some 170g/m paper types may not be punched easily. NOTE: Reliability and copy quantity are not guaranteed for all Special papers. Use only paper that is recommended by Konica. 4 - 11...
Page 53: Section 5: Copier Management
Section 5: Copier Management Power Saver Mode Auto Low Power Manual Low Power Auto Shut-Off Manual Shut-Off Entering an EKC Password Weekly Timer Function Timer Interrupt Copier Management Counter List Power Saver To Display the Counter List To Print the Counter List Weekly Timer/ Counter List...
Page 54: Power Saver Mode
Section 5 : Copier Management Power Saver Mode There are two modes for the Power saver as described below. Low power mode enables you to conserve energy by maintaining a lower fixing temperature during periods of copier inactivity. Shut-off mode conserves even more energy by partially turning OFF the power supply. CAUTION During Power Saver mode the copier is still connected to the mains power supply and power is still applied to certain areas of machine.
Page 55: Manual Low Power
Section 5 : Copier Management Power Saver Mode (Continued) Manual Low Power Press [ POWER SAVER ON/OFF ]. The Low Power Setting Screen will be displayed. Touch YES to activate the Low power mode. Low Power Setting Screen Copier Management Power Saver NOTE: The Manual low power setting can be selected by Key operator.
Page 56: Auto Shut-Off
Section 5 : Copier Management Power Saver Mode (continued) Auto Shut-Off This function automatically shuts off the main power after a specified period of copier inactivity. The Auto shut-off can be set for 30 minutes/ 60 minutes/ 90 minutes/ 120 minutes/ 240 minutes.
Page 57: Entering An Ekc Password
Section 5 : Copier Management Entering an EKC Password An EKC password is required only when the Electronic Key Counter (EKC) feature is activated; a User Password is assigned; and “Enter E.K.C. password” is displayed on the touch screen. Basic Screen Copier Copier Management...
Page 58: Weekly Timer Function
Section 5 : Copier Management Weekly Timer Function When a copier is under control of the weekly timer function, the TIMER indicator on the right side of the control panel is lit. TIMER Important: When the TIMER indicator is lit, the copier will INTERRUPT automatically be turned off.
Page 59 Section 5 : Copier Management Weekly Timer Function (continued) Timer Interrupt (continued) 4 Enter a 1-digit hour (ex. 3 hour is 3) using the keypad on INTERRUPT the control panel. (0 ~ 9) 5 Press [ START ]. PROOF COPY Input copy time is 3 hour(s) 05 minute(s)
Page 60: Counter List
Section 5 : Copier Management Counter List This function allows you to view the current indication of the following items as a list on the touch panel: Total counter, Copier counter, Printer counter, Counter start date. Check the list, then print it from the Counter List Screen, if desired. Counter List Screen Control Panel COUNTER...
Page 61: Section 6: Basic Operations
Section 6: Basic Operations How to Make a Basic Copy The Basic Screen Copy Mode Copy Mode Using RADF 1s2 Copy Mode Using Platen Glass Copy Density Automatic Exposure (AE) Manual Mode (Lighter, Normal, Darker) Density Shift Lens Mode Automatic Paper Selection (APS) Automatic Magnification Selection (AMS) Basic Preset and User Set Ratios...
Page 62 Section 6 : Basic Operations How to Make a Basic Copy The Basic Screen When power is turned on, the Basic Screen displays after warm-up; when Auto Power Saver mode is activated; when EKC password is set; when Key counter is used; or when Auto/Reset mode is manually or automatically restored.
Page 63 Section 6 : Basic Operations How to Make a Basic Copy (continued) Set Copying Conditions 1 Close the document feeder securely. 2 Press [ AUTO RESET ] to return to the initial status. 3 As required, set the copying conditions. NOTE: Be sure to complete the setting by resuming the Basic Screen.
Page 64 Section 6 : Basic Operations How to Make a Basic Copy (continued) Position Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original document FACE UP in the document feeder or FACE DOWN on the platen glass. HINTS: •...
Page 65: Copy Mode
2s2: Repeat, OHP interleave, Non-image area erase, Storing image in Overlay Memory, Server function Basic Screen Basic Basic Operation Operation Basic Copy Copy Mode 2-2 Copying Double-sided original Duplex copy 7075 7075 1-2 Copying 7075 7075 7075 Duplex copy Single-sided originals 7075 7075 7075 2-1 Copying...
Page 66: Copy Mode Using Radf
Section 6 : Basic Operations Copy Mode (continued) Copy Mode Using RADF Follow the procedure below to select the desired copy mode when using the document feeder to scan. Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch the desired mode key on the Basic Screen to highlight it.
Page 67 Section 6 : Basic Operations Copy Mode (continued) Copy Mode Using RADF (continued) Position Originals ... FACE UP in RADF Position original(s) FACE UP in the document feeder. Basic Operation HINTS: • For details on positioning originals, see p. 4-4. •...
Page 68: 1S2 Copy Mode Using Platen Glass
Section 6 : Basic Operations Copy Mode (continued) 1s2 Copy Mode Using Platen Glass When copying in 1s2 mode from the platen glass, use the Platen store mode. Refer to p. 6-29 for details of the Store mode. NOTE: See p. 4-3 for the information on unsuitable RADF originals. Basic Screen (with 1s2 mode and Store mode selected) Procedure Position Original ...
Page 69 Section 6 : Basic Operations Copy Mode (continued) 1s2 Copy Mode Using Platen Glass (continued) Enter Print Quantity Enter the desired print quantity, using the control panel keypad. To change the print quantity, press [ C (CLEAR QTY.) ], then enter the correct quantity.
Page 70: Copy Density
Section 6 : Basic Operations Copy Density Automatic Exposure (AE) AE operates with the initial settings. It detects the density of the original image and automatically selects the appropriate exposure for the copy. Manual Mode (Lighter, Normal, Darker) Select manual copy density to adjust exposure (density) when originals are too light or too dark.
Page 71: Density Shift
Section 6 : Basic Operations Copy Density (continued) Density Shift Density Shift divides each of nine density levels into two levels of lighter and three levels of darker. Density shift can be used in 4 density modes: Auto (Text/photo), Text, Photo, and Increase contrast.
Page 72 Section 6 : Basic Operations Copy Density (continued) Density Shift (continued) To set the Photo mode, touch Photo to highlight it, then press [ P (COUNT) ]. The following message will be displayed. Density Shift (Photo) 2 (0 ~ 5) To set the Increase contrast mode, touch Increase Contrast to highlight it, then press [ P (COUNT) ].
Page 73: Lens Mode
Section 6 : Basic Operations Lens Mode Automatic Paper Selection (APS) APS detects the size of originals placed on the RADF or platen glass and automatically selects and feeds copy paper of the same size, or selects an appropriate size according to the magnification ratio selected.
Page 74: Automatic Magnification Selection (Ams)
Section 6 : Basic Operations Lens Mode (continued) Automatic Magnification Selection (AMS) AMS is one of the initial settings that functions when the RADF is used and Paper Size is selected manually. ❒ Incompatible: APS, Change magnification, Dual page, Non-image area erase, Repeat, AUTO layout, Storing image in Overlay Memory An appropriate reduction or enlargement ratio will be selected automatically and applied to the image on the paper size.
Page 75: Preset And User Set Ratios
Section 6 : Basic Operations Lens Mode (continued) Preset and User Set Ratios Use the Preset and User Set ratios to increase or decrease magnification in fixed amounts. If required, the eight initially set Preset ratios shown below can be adjusted in the Key Operator mode.
Page 76: Zoom Mode
Section 6 : Basic Operations Lens Mode (continued) Zoom Mode Use the Zoom mode to reduce or enlarge the copied original image in 1% increments. ❒ Zoom range: 0.33 ~ 4.00 0.33 ~ 2.00 in 600 dpi mode and storing image in Overlay Memory Procedure 1 Touch ZOOM on the Basic Screen to display the popup menu for setting the zoom ratio.
Page 77: Vertical/Horizontal Zoom
Section 6 : Basic Operations Lens Mode (continued) Vertical/Horizontal Zoom Use the Vertical/Horizontal zoom mode to reduce or enlarge vertical and horizontal dimensions, independently. ❒ Vertical/Horizontal zoom range: 0.33~4.00 (0.33~2.00 in 600 dpi mode and storing image in Overlay Width Memory) Basic The figure shown below is the sample image using the Vertical/Horizontal zoom.
Page 78 Section 6 : Basic Operations Lens Mode (continued) Vertical/Horizontal Zoom (continued) The figure shown below is the sample image using the Vertical/Horizontal Zoom with an original placed slantwise on the platen glass. 30° Length: 0.50, Width: 2.00 Length: 2.00, Width: 0.50 30°...
Page 79: Paper Size
Section 6 : Basic Operations Paper Size The tray selection keys below PAPER SIZE are used to select a specific paper tray. When a specific tray is selected, the APS key will be deselected and the AMS key will be highlighted.
Page 80: Selecting Paper Type/Size For Multi-Sheet Bypass Tray
Section 6 : Basic Operations Paper Size (continued) Selecting Paper Type/Size for Multi-sheet Bypass Tray Specify the paper type and size when loading non-standard paper on the Multi-sheet bypass tray. Procedure 1 Open the Multi-sheet bypass tray, and load the copy paper on the tray. See p. 6-44 ~ p.
Page 81 Section 6 : Basic Operations Paper Size (continued) Selecting Paper Type/Size for Multi-sheet Bypass Tray (continued) Special Paper Type/Size Setting Screen • When STD size (special) is highlighted, the popup menu will appear. Basic Use arrows to scroll to the desired size. In this case, both the paper size and type Operation selected will be indicated on the Basic Screen.
Page 82 Section 6 : Basic Operations Paper Size (continued) Selecting Paper Type/Size for Multi-sheet Bypass Tray (continued) Special Paper Type/Size Setting Screen Special Paper Type/Size Setting Screen • When Wide size paper is highlighted, the popup menu will appear. Use arrows to scroll to the desired wide size, then specify the precise dimensions of paper to be used, following the procedure below.
Page 83: Set Reserve Job
Section 6 : Basic Operations Reserve Set Reserve Job The Reserve function allows you to set up a new job while a current (scan/print) job is in process. When the current job is finished, the Reserve job starts printing immediately. The FREE JOB key on the screen is touch sensitive and active only when another job is in progress;...
Page 84 Section 6 : Basic Operations Reserve (continued) Set Reserve Job (continued) Set Copying Conditions: Reserve Job 1 Touch the active FREE JOB to display the Reserve Job Setting Screen. Reserve Job Setting Screen 2 Set the desired copying conditions for the reserve job. When the Reserve Job Setting Screen is displayed, all keys on the LCD and Control panel will function for the reserve job.
Page 85: Job Status Screen
Section 6 : Basic Operations Reserve (continued) Job Status Screen Touch the STATUS key on the Basic Screen to display the Job Status Screen (see below). The Job Status Screen allows you to perform the following functions. • Confirm machine status •...
Page 86 Section 6 : Basic Operations Reserve (continued) Job Status Screen (continued) Contents of Job Status Screen NO. : Displays the No. (01-99) for each job assigned to the machine. MODE: Displays the machine’s current mode of operation. Four modes are listed below. COPIER PRINTER SCANNER...
Page 87: Mishandled Paper During The Reserve Setting
Section 6 : Basic Operations Reserve (continued) Mishandled Paper During the Reserve Setting If a misfeed occurs with the print/scan job in progress while you are setting a reserve job, the PRINT / SCAN key on the screen will change to JAM key. Basic Screen Basic Operation...
Page 88: When Paper Is Depleted For The Job In Progress
Section 6 : Basic Operations Reserve (continued) When Paper is Depleted for the Job in Progress If the paper supply for a print job in progress becomes depleted while you are setting a reserve job, the PRINT key on the screen will change to ADD PAPER key (blinking). In this case, you can still continue the reserve job setting.
Page 89: Store Mode
Section 6 : Basic Operations Store Mode Store mode allows you to scan multiple originals by touching the STORE key on the Basic Screen after setting copying conditions, and then outputting the complete set by pressing [ START ]. Platen Store Mode Use Platen store mode for originals that cannot be fed through the document feeder due to thickness, size or condition.
Page 90 Section 6 : Basic Operations Store Mode (continued) Platen Store Mode (continued) Place/Scan Originals on the Platen Glass ... FACE DOWN 1 Open the document feeder. 2 Place original FACE DOWN on the platen glass, then close the document feeder. IMPORTANT: PLACE AND SCAN THE ORIGINALS IN REGULAR ORDER OF PAGINATION.
Page 91 Section 6 : Basic Operations Store Mode (continued) Platen Store Mode (continued) Start Copying 1 Touch STORE to exit the Store mode. The STORE key INTERRUPT will return to the normal display. POWER ON / 2 Press [ START ] to print. All the data in memory will be PROOF COPY output.
Page 92: Radf Store Mode
Section 6 : Basic Operations Store Mode (continued) RADF Store Mode Use this feature to scan more than 100 original into memory from the RADF. Use this function in conjunction with the Reserve function to increase efficiency of the copying job. Specifications for RADF Store Mode ❒...
Page 93 Section 6 : Basic Operations Store Mode (continued) RADF Store Mode (continued) 1~100 101~200 FACE UP 101 2 3 Press [ START ] to scan and store the data into memory. Basic 4 Repeat steps 2 to 3 until all originals are scanned. Operation Memory indicator on the upper right of the Basic Screen allows you to check the remaining memory.
Page 94: Rotation
Section 6 : Basic Operations Rotation 90° Rotation This function allows you to utilize APS or AMS and copy the original documents onto size A4 or B5, irrespective of the copy paper feeding direction. By default, Rotation requires APS or AMS to function; however, the key operator may set the function to always function or when APS, AMS or reduce magnification functions.
Page 95: 90° Rotation And Ams
Section 6 : Basic Operations Rotation (continued) 90° Rotation and AMS For example, when size A4 copy paper is loaded in the tray in landscape orientation and copier detects that the original is placed in portrait orientation, Rotation (if required) rotates the original image by 90°...
Page 96: 180° Rotation
Section 6 : Basic Operations Rotation (continued) 180° Rotation In 1s2 copy mode, this function arranges the even pages of the simplex portrait originals upside down on the reverse side of duplex copies. In 2s1 copy mode, this function arranges the reverse sides of duplex portrait originals which read upside down to make normal simplex copies.
Page 97: Operation
Section 6 : Basic Operations Check Mode and Proof Copy Use the Check mode to confirm copying selections before pressing the [ START ] key. The Check Screen allows you not only to view the current settings but to change or release them directly from the Check mode.
Page 98 Section 6 : Basic Operations Check Mode and Proof Copy (continued) Make a Proof Copy 1 If necessary, press [ PROOF COPY ] on the control panel or touch PROOF COPY on the Check Screen to output a set of sample copy. Control Panel Check Screen INTERRUPT...
Page 99 Section 6 : Basic Operations Check Mode and Proof Copy (continued) Change/Release Settings If you want to change or release any settings, follow the procedure below. To change the settings: 1 Touch the desired copying condition key on the Check Screen to highlight it. Check Screen Basic Operation...
Page 100 Section 6 : Basic Operations Check Mode and Proof Copy (continued) To release the settings: 1 Touch the desired special original key or application function key on the Check Screen to highlight it. 2 Touch RELEASE SETTING . The confirmation screen will appear on the Check Screen. Check Screen 3 Touch YES to cancel the function, or NO to restore.
Page 101: Interrupt Mode
Section 6 : Basic Operations Interrupt Mode Use the Interrupt mode to interrupt copying in progress to perform a simple job. When interrupt copying is completed, the settings for the initial job restore automatically and the Basic Screen displays. Press the [ INTERRUPT ] key when the copier is in the following conditions: •...
Page 102 Section 6 : Basic Operations Interrupt Mode (continued) Replace Originals/Set Copying Conditions 1 Remove any document from the platen glass or from the document feeder, if present. 2 Place new original(s) on the platen glass or in the document feeder. 3 The copying settings in Interrupt mode are as follows.
Page 103: Help Mode
Section 6 : Basic Operations Help Mode Use the [ HELP ] key to access information about the current screen mode and to learn about setting procedures. The [ HELP ] key can be pressed from any screen except Job Memory and Key Operator Screens.
Page 104: Using The Multi-Sheet Bypass Tray
Section 6 : Basic Operations Using the Multi-Sheet Bypass Tray The Multi-sheet bypass tray can be used to stack regular 60 ~ 90g/m paper, or it can be used in the single-sheet mode to copy 50g/m thin stock or 170g/m thick stock.
Page 105 Section 6 : Basic Operations Using the Multi-Sheet Bypass Tray (continued) Load offset tabbed sheets so that the tab extensions are on the right at the rear (not front) of the tray. The top sheet is designated face up as the first tab of the finished set. Subsequent offset tab sheets follow in sequence.
Page 107: Output Modes
Section 7: Output Modes FS-108/108BM Finisher Specifications Non-Sort Mode Using Primary (Main) Tray Sort Mode Using Primary (Main) Tray Staple-Sort Mode Using Primary (Main) Tray Group Mode Using Primary (Main) Tray Output Modes Using Secondary (Sub) Tray Folding, Stapling & Folding and Trimming Modes Punching Mode Output Modes...
Page 108 Section 7 : Output Modes FS-108/108BM Finisher Specifications Use only paper that is recommended by Konica and stored under the environmental conditions stated for copy quality. Special stock is not guaranteed for reliability or copy quality. Multi-sheet bypass tray, Interrupt, and OHP interleaving are incompatible with finisher use.
Page 109 Section 7 : Output Modes FS-108/108BM Finisher Specifications (continued) Booklet Tray (FS-108BM Finisher only) • Folding Mode ❒ Paper size: A3, B4, A4R ❒ Paper weight: 60~90g/m ; Special stock (80g/m paper is recommended) ❒ Number of Folding sheet: 3 sheets max. ❒...
Page 110 Section 7 : Output Modes FS-108/108BM Finisher Specifications (continued) Trimmer Unit (FS-108BM Finisher only) • Trimming Mode ❒ Paper size: A3, B4, A4R, 8.5"x11"R ❒ Paper weight: 60~90g/m ; Special stock (80g/m paper is recommended) ❒ Number of trimmed sheet: 3 sheets max.
Page 111 Section 7 : Output Modes Non-Sort Mode Using Primary (Main) Tray The Non-sort mode simply means that the offset-stacker finisher modes are not selected. Copies will be stacked upon exit without being offset by sorted sets. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, FS- 108/FS-108BM outputs the printed sheets FACE DOWN in the proper order.
Page 112: Sort Mode Using Primary (Main) Tray
Section 7 : Output Modes Sort Mode Using Primary (Main) Tray Use this mode when you want to output multiple copies of the original set, and have each sorted set offset upon exit. The staple mode can be selected with the sort mode. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, FS- 108/FS-108BM outputs the printed sheets FACE DOWN in the proper order.
Page 113: Staple-Sort Mode Using Primary (Main) Tray
Section 7 : Output Modes Staple-Sort Mode Using Primary (Main) Tray Use this mode when you want to offset and staple each copied set. Stapling position and number of staples (1 or 2) can be designated on the Finisher Mode Selection Screen. With the Primary (main) tray initially selected on the Finisher Mode Selection Screen, FS- 108/FS-108BM outputs the printed sheets FACE DOWN in the proper order.
Page 114 Section 7 : Output Modes Staple-Sort Mode Using Primary (Main) Tray (continued) Procedure 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch STAPLE SORT on the Basic Screen to highlight it. The Staple Position icon will appear in the output icon display. When not changing the staple position, proceed to step 6.
Page 115 Section 7 : Output Modes Staple-Sort Mode Using Primary (Main) Tray (continued) 5 Touch OK on the Finisher Mode Selection Screen to complete the setting and return to the Basic Screen. The selection made in stapling position will be reflected in the output icon display. 6 Select additional copying features, as required.
Page 116: Group Mode Using Primary (Main) Tray
Section 7 : Output Modes Group Mode Using Primary (Main) Tray Use this mode when you want to group together multiple copies of each original, and offset the sets upon exit. Grouped sets cannot be stapled. ❒ Incompatible Basic copying conditions: 2s1 or 2s2 mode using platen glass, Proof copy, Folding, Stapling &...
Page 117: Output Modes Using Scondary (Sub) Tray
Section 7 : Output Modes Output Modes Using Secondary (Sub) Tray In addition to the Primary (main) tray, Finisher FS-108/FS-108BM is equipped with a Secondary (sub) tray that can be selected on the Finisher Mode Selection Screen. The Secondary (sub) tray provides 4 types of output mode as specified below, also to be specified on the Finisher Mode Selection Screen.
Page 118 Section 7 : Output Modes Output Modes Using Secondary (Sub) Tray (continued) Procedure 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch OUTPUT MENU on the Basic Screen to display the Finisher Mode Selection Screen. 3 Touch SUB TRAY , then touch the desired key(s) on the popup menu to specify one of the four output modes.
Page 119: Folding, Stapling & Folding, And Trimming Modes
Section 7 : Output Modes Folding, Stapling & Folding, and Trimming Modes The Folding and Stapling & Folding modes are available only when the FS-108BM Finisher option is installed. The Trimming modes (Folding and Trimming, Stapling & Folding and Trimming) are available only when the TU-108 Trimmer unit option is installed on the FS- 108BM Finisher.
Page 120 Section 7 : Output Modes Folding, Stapling & Folding, and Trimming Modes (continued) ❒ Incompatible conditions with Booklet selected Basic copying conditions: 1s1, 2s1, APS, Sort, Staple-sort, Group, Cover sheet feeding, Rotation Sort, Rotation Group, Punching, Z-Folding Special Originals: Resolution (Very high), Mixed Original, Non STD Size Applications: Sheet/Cover Insertion, Combination, OHP Interleave, Program Job, Non- image Area Erase, Repeat, Frame/Fold Erasure, AUTO Layout, Shift mode in Image Shift, Overlay...
Page 121 Section 7 : Output Modes Folding, Stapling & Folding, and Trimming Modes (continued) 4 Touch OK on the Finisher Mode Selection Screen. The Basic Screen will be restored and the selection made in the output mode will be reflected in the output icon display. 5 Select additional copying features, as required.
Page 122: Punching Mode
Section 7 : Output Modes Punching Mode The Punching mode is available only when the PU-108 Punching unit option is installed on the FS-108/FS-108BM finisher. When the Punching mode is selected in combination with any of the Primary (Main) tray output modes, each copied sheet is punched and output to the Primary tray according to the selected output mode.
Page 123 Section 7 : Output Modes Punching Mode (continued) 4 Touch the desired punch position key on the screen to highlight it. Punch Position Selection Screen 5 Touch OK on the Punch Position Selection Screen to restore the Finisher Mode Selection Screen. 6 Touch OK on the Finisher Mode Selection Screen to complete the setting and return to the Basic Screen.
Page 124: Punching / Z-Folding Mode
Section 7 : Output Modes Punching / Z-Folding Mode The Punching / Z-Folding mode is available only when the PZ-108 Punching / Z-Folding unit option is installed on the FS-108/FS-108BM finisher. With this option, the Punching mode and Z-Folding mode can be used individually or in combination. When the Punching and Z-Folding modes are selected in combination with any of the Primary (Main) tray output modes, each copied sheet is punched and Z-folded, then output to the Primary tray according to the selected output mode.
Page 125 Section 7 : Output Modes Punching / Z-Folding Mode (continued) Capacity for Mixed Size Originals using Z-Folding and Staple-Sort with APS Capacity for one stapled set Primary Tray Capacity Number of Z-folded sheets Number of regular sheets 1 sheet 1 ~ 40 sheets 20 stapled sets 0 ~ 30 0 ~ 20...
Page 126 Section 7 : Output Modes Punching / Z-Folding Mode (continued) 4 When PUNCH is selected, the Punch Position Selection Screen will be displayed. Touch the desired punch position key on the screen to highlight it. Punch Position Selection Screen 5 Touch OK on the Punch Position Selection Screen to restore the Finisher Mode Selection Screen.
Page 127: Cover Sheet Feeder
Section 7 : Output Modes Cover Sheet Feeder The Cover Sheet Feeder (PI-108) is available as an option on the FS-108BM finisher. Load cover sheet paper into this device and use the sheets as front covers for copied sets output to the Main tray; or use the sheets as booklet type covers for copied sets output to the Booklet tray in the Folding or Stapling &...
Page 128 Section 7 : Output Modes Cover Sheet Feeder (continued) Cover Sheet Insert Selection Screen 4 Touch FRONT , FRONT+BACK , or BACK to highlight it. 5 Touch OK on the Cover Sheet Insert Selection Screen. The Finisher Mode Selection Screen will be restored. 6 Touch OK on the Finisher Mode Selection Screen.
Page 129: Manual Stapling
Section 7 : Output Modes Manual Stapling The Manual Stapling function is available only with the Cover Sheet Feeder option (PI- 108) installed on the FS-108BM Finisher. To use this convenient function, simply place a set of paper to be stapled into the cover sheet feeder of the finisher, select the desired staple mode from the manual stapling control panel located on the top of the finisher, then press the Staple Start/Stop button.
Page 130 Section 7 : Output Modes Manual Stapling (continued) Procedure 1 Place a set of paper to be stapled into the cover sheet feeder, then align the guide plate. The indicator light of Staple Start/Stop button will turn green. NOTE: Refer to the specifications on previous page for available paper size in each mode.
Page 131: Output Mode For Machine Without Finisher
Section 7 : Output Modes Output Mode for Machine without Finisher This section describes the following eight output modes for a copier without the Finisher. q Face down non-sort exit (default) t Face up non-sort exit w Face down rotation exit y Face up rotation sort exit e Face down group exit u Face up group exit...
Page 132: Face Down Exit
Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Down Exit • Non-sort mode copies the original set in amounts determined by the print quantity setting, the outputs sorted sets normally. • Rotation sort mode rotates every other sorted sets by 90° upon exit, provided the same paper size is loaded in two trays, one tray with paper loaded in portrait orientation and the other tray with paper loaded in landscape orientation.
Page 133 Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Down Exit (continued) To Set Face Down Rotation Sort Exit Basic Screen Output Menu Screen 1 Confirm that the OUTPUT MENU key is not highlighted. If OUTPUT MENU is highlighted, touch OUTPUT MENU to display the Output Menu Output Screen.
Page 134 Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Down Exit (continued) To Set Face Down Rotation Group Exit Basic Screen Output Menu Screen 1 Touch OUTPUT MENU on the Basic Screen to display the Output Menu Screen. 2 Touch ROTATION GROUP and FACE DOWN to highlight them.
Page 135: Face Up Exit
Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Up Exit Unless Face up exit is selected, all simplex copies and odd numbered duplex copies exit to the tray face down. When Face up exit is selected, all simplex copies and odd numbered duplex copies exit face up.
Page 136 Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Up Exit (continued) To Set Face Up Rotation Sort Exit Basic Screen Output Menu Screen 1 Touch OUTPUT MENU to display the Output Menu Screen. 2 Touch FACE UP to highlight it. 3 Touch OK to complete the setting and return to the Basic Screen.
Page 137 Section 7 : Output Modes Output Mode for Machine without Finisher (continued) Face Up Exit (continued) To Set Face Up Rotation Group Exit Output Menu Screen Basic Screen 1 Touch OUTPUT MENU on the Basic Screen to display the Output Menu Screen. 2 Touch ROTATION GROUP and FACE UP to highlight them.
Page 138: Tandem Mode
Section 7 : Output Modes Tandem Mode Tandem mode enables your 7075 primary (master) copier to work in tandem with the 7075 secondary (sub) copier connected using a cross cable, for the purpose of providing faster completion of large copying jobs. Two units working in tandem distribute a job in half the time of non-tandem mode.
Page 139 Section 7 : Output Modes Tandem Mode (continued) Turn Power ON ... Both Copiers 1 Turn power on by pressing the Power switches of the two copiers. 2 Confirm that both copiers are ready to copy with the Basic Screen displayed. Set Copying Conditions 1 Touch OUTPUT MENU on the Basic Screen of either copier to display the Finisher Mode Selection Screen.
Page 140 Section 7 : Output Modes Tandem Mode (continued) NOTE: The tandem mode cannot be selected/continued in the cases shown below. The message “Please wait/ Reserve is not available in Slave unit,” “Slave unit error/ Please check slave unit,” or “Please check slave unit”...
Page 141 Section 7 : Output Modes Tandem Mode (continued) Position Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass of the primary copier. Start Tandem Mode Copying Output Modes Press [ START ] on the control panel of the primary copier.
Page 142 Section 7 : Output Modes Tandem Mode (continued) To cancel the tandem copying job: 1 Press [ STOP ] on the control panel of the primary copier. TIMER The scanning/printing job stops immediately, and the INTERRUPT popup menu appears on the Basic Screen of the primary POWER SAVER ON / OFF copier to ask you whether to continue or terminate the...
Page 143 Section 7 : Output Modes Tandem Mode (continued) Troubleshooting Copying with the Allocation recovery mode: The Allocation recovery mode enables you to complete your copying job even when trouble occurs in either the primary or secondary copier, such as a paper jam. In that case, the copier that is trouble free completes the job.
Page 145: Section 8: Special Original
Section 8: Special Original Special Original Screen Resolution (Image Quality) High Mode Very High Mode 600 Dpi Special Original Screen Text/Photo Enhance Resolution Special Original Text/Photo Enhance Mixed Original Z-Folded Original Mixed Original SDF (Single Document Feed) Z-Folded Original Original Size Original Size Special Original...
Page 146: Special Original Screen
Section 8 : Special Original Special Original Screen When SPECIAL ORIGINAL on the Basic Screen is touched, the Special Original Screen will be displayed. If one function on the menu is incompatible with another, it will appear dimmed. The function keys initially selected for each of four sections are highlighted. Touch and highlight the desired key to change the standard setting.
Page 147: Resolution (Image Quality)
Fewer originals can be copied at one time. Special NOTE: Original Screen Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. Resolution Specifications for High Mode ❒...
Page 148 Section 8 : Special Original Resolution (Image Quality) (continued) High Mode (continued) Place Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) in the document feeder or on the platen glass. HINTS: • For details on positioning originals, see p. 4-2 and p. 4-4. •...
Page 149: Very High Mode
Section 8 : Special Original Resolution (Image Quality) (continued) Very High Mode Very High resolution is used for high quality photo output, and incompatible with any other copying condition that uses memory. Specifications for Very High Mode ❒ Use platen glass only. ❒...
Page 150 Section 8 : Special Original Resolution (Image Quality) (continued) Very High Mode (continued) Place Originals ... FACE DOWN on Platen Glass Position original(s) on the platen glass. HINTS: • For details on positioning originals, see p. 4-2. • For original and copy paper information, see Section 4. Start Copying Press [ START ] to scan.
Page 151: 600 Dpi
Select 600 dpi mode to improve the copy image. This mode uses more memory than the normal default mode or the High mode. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. Specifications for 600 Dpi Mode ❒...
Page 152 Section 8 : Special Original Resolution (Image Quality) (continued) 600 Dpi (continued) Place Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) in the document feeder or on the platen glass. HINTS: • For details on positioning originals, see p. 4-2 and p. 4-4. •...
Page 153: Text/Photo Enhance
In cases where the image is light and background is dark, the background will not be changed. Special Special Original Original Original AUTO mode Photo mode Konica Corporation Konica Corporation Konica Corporation Konica Corporation Konica Corporation Konica Corporation Konica Corporation Konica Corporation Konica Corporation...
Page 154 Section 8 : Special Original Text/Photo Enhance (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch SPECIAL ORIGINAL on the Basic Screen to display the Special Original Screen. 3 Touch Increase Contrast , Photo , or Text , as required. Special Original Screen 4 Select additional copying features, as desired.
Page 155 Section 8 : Special Original Text/Photo Enhance (continued) Start Copying Press [ START ] to scan. Memory indicator on the upper right of the Basic Screen INTERRUPT allows you to check the remaining memory. POWER ON / Printing job starts in succession when the machine PROOF COPY becomes ready for output.
Page 156: Special Original
Section 8 : Special Original Special Original Mixed Original Use the Mixed original mode with the document feeder to copy [A3, B4, A4R, A4, B5 and A5 originals mixed], [B4, A4R, B5R, B5 and A5 originals mixed], [A4R, B5R and A5 originals mixed], or [B5R and A5R originals mixed].
Page 157 Section 8 : Special Original Special Original (continued) Mixed Original (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch SPECIAL ORIGINAL on the Basic Screen to display the Special Original Screen. 3 Touch Mixed Original to highlight it.
Page 158 Section 8 : Special Original Special Original (continued) Mixed Original (continued) Enter Print Quantity Enter the desired print quantity. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity. Place Originals ... FACE UP in RADF Position mixed originals FACE UP in the document feeder.
Page 159: Z-Folded Original
Section 8 : Special Original Special Original (continued) Z-Folded Original Use the Z-folded original mode with the document feeder to copy Z-folded originals that may cause the size detection sensor of the RADF to function incorrectly. This mode will detect the original size while scanning the original image, taking more time than usual scanning job.
Page 160 Section 8 : Special Original Special Original (continued) Z-Folded Original (continued) Enter Print Quantity Enter the desired print quantity. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity. Place Originals ... FACE UP in RADF Position Z-folded original(s) in the document feeder.
Page 161: Sdf (Single Document Feed)
Section 8 : Special Original Special Original (continued) SDF (Single Document Feed) Use the SDF mode to copy thick originals or paste-ups to be fed one sheet at a time in the document feeder. NOTE: Key operator can set the machine to automatically feed the original one second after placing the original in the document feeder (Auto Start), when the SDF mode is used together with RADF store mode.
Page 162 Section 8 : Special Original Special Original (continued) SDF (Single Document Feed) (continued) Place Originals ... FACE UP in RADF Normal SDF mode: Position a sheet of original in the document feeder. Never set more than one original, otherwise machine trouble may be caused. NOTES: •...
Page 163 Section 8 : Special Original Special Original (continued) SDF (Single Document Feed) (continued) Start Copying Press [ START ]. In normal SDF mode, the original will be fed and scanned, INTERRUPT then printing job will start in succession when the machine POWER ON / becomes ready for output.
Page 164: Original Size
Section 8 : Special Original Original Size The copier usually detects the standard size of originals fed through RADF or positioned on the platen glass (STD size mode). Use Non STD size mode to specify the scanning area manually for copying or printing special size originals.
Page 165 Section 8 : Special Original Original Size (continued) Enter Print Quantity Enter the desired print quantity. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity. Place Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) FACE UP in the document feeder, or FACE DOWN on the platen glass.
Page 167: Section 9 : Applications
Application Function Menu Sheet/Cover Insertion Chapter Section 9 : Applications Combination Booklet Application Function Menu Interleave Sheet/Cover Insertion Image Insert Chapter Dual Page Combination Program Job Non-Image Booklet Area Erase Reverse Image OHP Interleave Repeat Image Image Insert Frame/Fold Erasure Dual Page AUTO Layout All-Image...
Page 168: Application Function Menu
Section 9 : Applications Application Function Menu When APPLICATION key on the Basic Screen is touched, the Application Selection Screen displays on the touch panel. If one function on the menu is incompatible with another, it will appear dimmed. The function always dimmed on the screen is now under development. When a function key is touched, it becomes highlighted.
Page 169: Sheet/Cover Insertion
❒ Scan and store originals into memory, then print all the pages collectively. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Use RADF store mode when the original count exceeds 100.
Page 170 Section 9 : Applications Sheet/Cover Insertion (continued) Insertion Mode This mode is classified as Copy insertion and Blank insertion. The Copy insertion mode copies and inserts plain or coloured sheets at locations designated in the page setting area of the Sheet/Cover Insertion Screen. The Blank insertion mode inserts non copied (plain or coloured) sheets.
Page 171 Sheet/Cover Section 9 : Applications Insertion Sheet/Cover Insertion (continued) Basic Functions Combination samples 9 10 9 10 8 9 10 SURVEYOR’S SURVEYOR’S REPORT REPORT SURVEYOR’S SURVEYOR’S REPORT REPORT Originals Copies Originals Copies FRONT COVER COPIED FRONT & BACK COVERS COPIED 9 10 9 10 9 10...
Page 172 Section 9 : Applications Sheet/Cover Insertion (continued) Procedure Load Paper for Copies, Insertions and Covers Load regular sheets into any tray, and load insert sheets and covers of the same size as regular sheets into each tray source to be designated on the Sheet/Cover Insertion Screen.
Page 173 Sheet/Cover Section 9 : Applications Insertion Sheet/Cover Insertion (continued) 5 Select Back Cover Insertion. Touch BACK COPY to insert a copied back cover, or BACK BLANK to insert a blank back cover. Return to step 4 to select Front Cover Insertion, if desired. Proceed to step 6 to select Sheet Insertion, if desired.
Page 174 Section 9 : Applications Sheet/Cover Insertion (continued) Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [C (CLEAR QTY.)] and enter the correct quantity. Position Originals ... FACE UP Position originals FACE UP in the document feeder. HINTS: •...
Page 175 ❒ Scan and store originals into memory, then print all the pages collectively. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Use RADF store mode when the original count exceeds 100.
Page 176 Section 9 : Applications Chapter (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [AUTO RESET]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 3 Touch Chapter . The Chapter Insertion Setting No. Screen will be displayed. The 1s2 mode is automatically selected.
Page 177 Section 9 : Applications Chapter Chapter (continued) 7 When all entries are made, touch OK to return to the Application Selection Screen. 8 Make additional Application selections if desired, then touch OK to return to the Basic Screen. Enter Print Quantity Enter the desired print quantity, using keypad.
Page 178: Combination
❒ Scan and store originals into memory, then print all the pages collectively. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Use RADF store mode when the original count exceeds 100.
Page 179 Section 9 : Applications Combination (continued) Combination Procedure Set Copying Conditions 1 Close the RADF securely, then press [AUTO RESET]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 3 Touch Combination to display the Combination Mode Selection Screen. Application Selection Screen Combination Mode Selection Screen Applications...
Page 180 Section 9 : Applications Combination (continued) Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [C (CLEAR QTY.)] and enter the correct quantity. Position Originals ... FACE UP Position originals FACE UP in the document feeder. HINTS: •...
Page 181: Booklet
❒ Scan and store originals into memory, then print all the pages collectively. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Use RADF store mode when the original count exceeds 100.
Page 182 Section 9 : Applications Booklet (continued) Procedure Load Copy Paper Load A3, B4, A4R, A4, or B5R copy paper in a tray. When selecting cover sheet mode ( Cover with Copy sheet or Cover with Blank sheet ), load the same size paper in any other tray unless it is specified as Thick 2 or Tab paper of the paper type in the Key operator mode.
Page 183 Section 9 : Applications Booklet (continued) 6 Select additional Applications, as desired. Booklet • Using the Reduce & shift mode of Image shift will make a binding area in the centre of the copies, as shown on the right. See p. 9-51 to p. 9-54 for details of Reduce & shift mode.
Page 184 Section 9 : Applications Booklet (continued) Position Originals ... FACE UP Position A4R, A4, or B5 originals FACE UP onto the document feeder. NOTE: When loading originals, heed the following limits on capacity: Folding mode 6 pages or less for simplex copying 12 pages or less for duplex copying Stapling &...
Page 185 Section 9 : Applications Booklet (continued) CAUTION Booklet When the finisher / paper exit tray capacity is exceeded due to the print quantity selected, remove the copied sets as they exit; otherwise, mishandled paper will occur. CAUTION When the Booklet tray / Trimmer unit tray capacity is exceeded, the finisher will cease operating.
Page 186: Ohp Interleave
Section 9 : Applications OHP Interleave Use the OHP interleave function in 1s1 or 2s1 mode to copy onto overhead projection transparencies, and output a blank or copied interleaf sheet with each copied transparency. In the blank mode, a blank interleaf sheet is output with each transparency to keep the film material from sticking together.
Page 187 Section 9 : Applications OHP Interleave (continued) Set Copying Conditions Interleave 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch Bypass on the Basic Screen, then touch PAPER TYPE/SIZE to display the Paper Type/Size Setting Screen. Touch OHP , then OK to return to the Basic Screen. 3 Touch APPLICATION on the Basic Screen to display the Application Selection Screen.
Page 188 Section 9 : Applications OHP Interleave (continued) Position Originals ... FACE UP Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass. HINTS: • For details on positioning originals, see p. 4-2 and p. 4-4. •...
Page 189: Image Insert
❒ Store mode will be automatically selected. See p. 6-29 to p. 6-33 for details. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Max. image insert: 30 locations, from p. 0 to p. 999 ❒...
Page 190 Section 9 : Applications Image Insert (continued) Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 3 Touch Image Insert to display the Image Insertion No. Setting Screen. Application Selection Screen Image Insertion No.
Page 191 Section 9 : Applications Image Insert (continued) Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity. Image Insert RADF: Place/Scan Originals ... FACE UP Scan the document feeder images.
Page 192 Section 9 : Applications Image Insert (continued) Start Copying Touch STORE to deselect the Store mode, then press [ START ]. INTERRUPT The copier will start printing when ready for output. POWER ON / PROOF COPY To suspend the printing job, press [ STOP ]. STOP After copying is completed, all the scanned data will be deleted automatically.
Page 193: Dual Page
❒ Store mode will be automatically selected. See p. 6-29 to p. 6-33 for details. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine. ❒ Original size: A3, B4...
Page 194 Section 9 : Applications Dual Page (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 3 Touch Dual Page to enter the Dual Page Screen. Application Selection Screen Dual Page Screen 4 Touch Facing pages , Front cover + Facing pages , or Front/Back cover + Facing...
Page 195 Section 9 : Applications Dual Page (continued) Place/Scan Originals Using Platen Glass ... FACE DOWN 1 Position the open book or sheet on the platen glass in the right rear corner, aligning the edge with the right measuring guide. To output the set in the same order as the originals, start scanning from the first page.
Page 196 Section 9 : Applications Dual Page (continued) Start Copying Touch STORE to deselect the Store mode, then press [ START ]. INTERRUPT The copier will start printing when ready for output. POWER ON / PROOF COPY To suspend the printing job, press [ STOP ]. STOP After copying is completed, all the scanned data will be deleted automatically.
Page 197: Program Job
Section 9 : Applications Program Job In the ordinary Store mode, the combined features selected for the job are applied to all originals to be scanned. In the Program Job mode, you may scan multiple sets of originals and apply different settings on each set (referred to as JOB), then output them all as a complete set.
Page 198 Section 9 : Applications Program Job (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 3 Touch Program Job . The incompatible function keys will be dimmed to show inactivity. Application Selection Screen 4 Make additional application selections, or touch OK to return to the Basic Screen.
Page 199 Section 9 : Applications Program Job (continued) 2 When scanning for the current JOB is completed, the popup menu will be displayed in the Basic Screen. To store the current JOB images, touch DECISION . To delete the images, touch CANCEL . Basic Screen Program Job 3 Repeat steps 1 to 2 until all JOB originals are scanned.
Page 200: Non-Image Area Erase
Section 9 : Applications Non-Image Area Erase The Non-image area erase mode is used to copy non standard or special originals, such as books, magazines, paste-ups, graphs, thick or thin materials, etc. from the platen glass. The exposed glass area outside the borders of the original will not be copied. This mode helps to preserve the condition of originals;...
Page 201 Section 9 : Applications Non-Image Area Erase (continued) Procedure Set Copying Conditions 1 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 2 Touch Non-Image Area Erase . The incompatible function keys will be dimmed to show inactivity. Application Selection Screen Non-Image Area Erase...
Page 202 Section 9 : Applications Non-Image Area Erase (continued) Start Copying Press [ START ] to scan. INTERRUPT Printing job starts in succession when the machine POWER ON / becomes ready for output. PROOF COPY To suspend the scanning or printing job, press [ STOP ]. STOP After copying is completed, all the scanned data will be deleted automatically.
Page 203: Reverse Image
Section 9 : Applications Reverse Image Use Reverse image to reverse the image from black-on-white to white-on-black, and vice versa. Specifications for Reverse Image ❒ Incompatible Basic Copying Conditions: Folding, Stapling & Folding, Trimming ❒ Incompatible Special Originals: None ❒ Incompatible Applications: Non-image Area Erase, Repeat, All-image Area, Overlay Memory Non-Image Area Erase...
Page 204 Section 9 : Applications Reverse Image (continued) Position Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass. HINTS: • For details on positioning originals, see p. 4-2 and p. 4-4. •...
Page 205: Repeat Image
Section 9 : Applications Repeat Image Use Repeat image to create labels, business cards, tickets, etc., by repeating the selected image down the page. Vertical/Horizontal Width Setting mode Repeat the selected image area of 10mm ~ 150mm in both vertical and horizontal widths measured from the rear right corner of the A3 original area indicated on the right edge of the platen glass.
Page 206 Section 9 : Applications Repeat Image (continued) Specifications for Repeat Image ❒ Vertical/Horizontal Width Setting Mode Specifications Use the platen glass. (Document feeder cannot be used.) Repeat width: 10 ~ 150mm (in 1mm increments) Copy mode: 1s1 mode only (When selecting 1s2 mode, Platen store mode will function automatically.) ❒...
Page 207 Section 9 : Applications Repeat Image (continued) Procedure Set Copying Conditions 1 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 2 Touch Repeat to display the Repeat Mode Selection Screen. Application Selection Screen Repeat Image Repeat Mode Selection Screen Applications 3 To select the Manual setting mode: (1) Touch Vertical/Horizontal to highlight it.
Page 208 Section 9 : Applications Repeat Image (continued) To select the Auto setting mode, touch AUTO . Non-image area erase will function automatically. To select the Repeat mode, touch 2 Repeat , 4 Repeat , or 8 Repeat , as desired. 4 Touch OK to return to the Application Selection Screen.
Page 209 Section 9 : Applications Repeat Image (continued) Start Copying Press [ START ] to scan. Printing job starts in succession when the machine INTERRUPT becomes ready for output. POWER ON / PROOF COPY To suspend the scanning or printing job, press [ STOP ]. STOP After copying is completed, all the scanned data will be deleted automatically.
Page 210: Frame/Fold Erasure
Section 9 : Applications Frame/Fold Erasure Use Frame/Fold Erasure to eliminate black copy marks along borders. Specifications for Frame/Fold Erasure ❒ Frame erasure amount: 1~15 mm in 1 mm increments ❒ Fold erasure amount: 1~30 mm in 1 mm increments ❒...
Page 211 Section 9 : Applications Frame/Fold Erasure (continued) 3 Touch Frame Erasure (All sides) or Frame Erasure (Each side) . Touch Fold Erasure to use the Fold erasure mode. • Touch Frame Erasure (All sides) to enter the frame erasure amount of the up, down, right and left sides collectively using the touch screen keypad or up/down arrow key, from 1 to 15mm.
Page 212 Section 9 : Applications Frame/Fold Erasure (continued) 4 Touch OK to complete the setting. The Application Selection Screen will be displayed. 5 Make additional application selections, or touch OK to return to the Basic Screen. Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity.
Page 213: Auto Layout
Section 9 : Applications AUTO Layout Use this function to detect the image area of the original and centre the whole image on the copy paper. Specifications for AUTO Layout ❒ Copy mode is automatically set to 1s1; 1s2 mode is also available only when using Store mode.
Page 214 Section 9 : Applications AUTO Layout (continued) 4 Touch OK to complete the setting and return to the Basic Screen. APS and AMS are automatically released. 5 Select the desired magnification and paper size. Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity.
Page 215: All-Image Area
Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. AUTO Layout All-Image Area 7075 7075 7075 Original Normal Copy All-image Area Applications Applications 3 Touch All-image Area .
Page 216 Section 9 : Applications All-Image Area (continued) Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity. Position Originals ... FACE UP in RADF FACE DOWN on Platen Glass Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass.
Page 217: Image Shift
Platen store mode is automatically selected. See p. 6-29 to p. 6-33 for details. NOTE: Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine.
Page 218 Section 9 : Applications Image Shift (continued) Procedure Set Copying Conditions 1 Close the RADF securely, then press [ AUTO RESET ]. 2 Select 1s1, 1s2, 2s2 or 2s1 copy mode from the Basic Screen, as required. 3 Touch APPLICATION on the Basic Screen to display the Application Selection Screen. 4 Touch Image Shift to display the Image Shift Selection Screen.
Page 219 Section 9 : Applications Image Shift (continued) Image Shift Selection Screen 7 To set shift amount in Reduce & Shift: (1) Touch FRONT . In Reduce & Shift mode, the BOTH SIDES key appears dimmed to show inactivity. The message “Select magnification ratio on FRONT side” will be displayed when BACK is selected first.
Page 220 Section 9 : Applications Image Shift (continued) 9 Touch OK to complete the setting and return to the Application Selection Screen. 10 Select additional Application functions, or touch OK to return to the Basic Screen. Enter Print Quantity Enter the desired print quantity, using keypad. To change the print quantity, press [ C (CLEAR QTY.) ] and enter the correct quantity.
Page 221: Stamp
Section 9 : Applications Stamp Stamp allows you to print regular stamp, numbering, page numbering, date and time, watermark, and watermark numbering onto the output copies. These 6 types of stamps can be used individually or in multiple combinations. • STAMP prints the letters selected from 8 options onto the scanned image at the location designated on the screen.
Page 222 Section 9 : Applications Stamp (continued) TOP SECRET Top-Left T-Middle T-Right STAMP ’00/10/10 10:30AM DATE/TIME Middle-Left Middle M-Right WATERMARK 2 / 5 0001/1000 PAGE NUMBERING 0001/1000 0001/1000 0001/1000 [0002 / 0005] Lower-Left L-Middle L-Right 0001/1000 0001/1000 Positions of other stamps SET NUMBERING WATERMARK NUMBERING Application Selection Screen...
Page 223 Section 9 : Applications Stamp (continued) 4 Touch to select the desired stamp to display the subsequent screen. On each screen, you can specify the desired type of the selected stamp. Stamp Selection Screen Set Numbering Type Selection Screen Date/Time Type Selection Screen Page Numbering Type Selection Screen Watermark Selection Screen Watermark Numbering Type Selection Screen...
Page 224 Section 9 : Applications Stamp (continued) 6 Touch CHARACTER SIZE , if desired, to change the character size. The following options are provided: STAMP : LARGER/ SMALLER SET NUMBERING : 20pt/ 36pt PAGE NUMBERING : 8pt/ 10pt/ 12pt/ 14pt DATE/TIME : 8pt/ 10pt/ 12pt/ 14pt 7 Touch PRINTED PAGE on the Stamp Selection, Set Numbering Type Selection, or Date/Time Type Selection Screen to designate whether to print the selected stamp...
Page 225 Section 9 : Applications Stamp (continued) When Chapter is already selected, touching STARTING No. on the Set Numbering, Page Numbering, or Watermark Numbering Type Selection Screen will display the Starting No. Setting Screen with Chapter starting number setting (see below). Touch CHAPTER NUMBER or PAGE NUMBER to highlight it, then use the touch screen keypad or up/down arrow key to enter the desired starting number for each.
Page 226 Section 9 : Applications Stamp (continued) Start Copying Press [ START ]. INTERRUPT The copier will start printing when ready for output. POWER ON / PROOF COPY To suspend the printing job, press [ STOP ]. After copying is completed, all the scanned data will be STOP deleted automatically.
Page 227: Overlay
Section 9 : Applications Overlay Use Overlay to scan an image, then overlay the image onto each page copied in the job. Overlay Specifications ❒ Scan and store originals into memory. ❒ APS and AMS are automatically released. ❒ Magnification is initially set to 1:1. This setting is changeable. ❒...
Page 228 Section 9 : Applications Overlay (continued) Position Original(s) ... FACE UP in RADF FACE DOWN on Platen Glass 1 Position the overlaying original in the document feeder or on the platen glass, then press [ START ] to scan. 2 The second and subsequent pages are to be overlaid in printing. Place them in the document feeder or on the platen glass, then press [ START ].
Page 229: Overlay Memory
Section 9 : Applications Overlay Memory Use Overlay Memory to scan and store several images in HDD*, then recall the desired image from the HDD to overlay onto each page copied in the job. NOTE*: Installation of the optional HDD (HD-102) is required. Stored overlaying image Scanned originals Copies in OVERLAY MEMORY mode...
Page 230 Section 9 : Applications Overlay Memory (continued) To Store Overlaying Image Data in HDD (continued) 4 Touch OVERLAY MEMORY to display the Overlaying Image Selection Screen. NOTE: Without HDD, the OVERLAY MEMORY key will be dimmed on the Stamp/Overlay Selection Screen to show inactivity.
Page 231 Section 9 : Applications Overlay Memory (continued) To Store Overlaying Image Data in HDD (continued) Image Name Entry Screen Image Name Entry Screen Basic Screen to store overlaying image Overlaying Image Data Storing Screen Place/Scan Originals ... FACE DOWN Position the overlaying original on the platen glass, then Stamp/Overlay Overlay Memory press [ START ] to scan.
Page 232: To Overlay Image Stored In Hdd
Section 9 : Applications Overlay Memory (continued) To Overlay Image Stored in HDD The following procedure describes how to overlay the image stored in HDD onto each page copied in the job. Specifications for Overlay Copying in Overlay Memory ❒ APS and AMS are automatically released. ❒...
Page 233 Section 9 : Applications Overlay Memory (continued) To Overlay Image Stored in HDD (continued) 7 Touch OK to return to the Application Selection Screen. 8 Make additional application selections, or touch OK to return to the Basic Screen. 9 The Store mode is automatically selected, and APS and AMS are released. Set the desired Copy mode, Copy density, Lens mode, and Copy size on the Basic Screen.
Page 235: Section 10: Job Memory
Section 10: Job Memory Job Store Job Recall Job Memory Form Job Store Job Recall Job Memory Form Memory...
Page 236: Job Store
Section 10 : Job Memory Job Store Use Job Store to store up to 30 frequently-used copying jobs, which can be recalled at any time. The stored jobs can be given alphabetical names. ❒ All copying functions can be selected Procedure 1 Make job selections from the Basic Screen, Application Selection Screen, Special Original Screen and/or Output Mode Screen.
Page 237 Section 10 : Job Memory Job Store (continued) 5 When the Job No. Selection Screen is restored, touch one of the keys numbered from 1~30 to store the job under that number. The key with a lock icon ( ) displayed is locked and cannot be selected.
Page 238: Job Recall
Section 10 : Job Memory Job Recall Use Job Recall to recall jobs that are already stored in Job Memory. Procedure 1 Place original(s) as required for the job you are about to recall. 2 Press [ JOB MEMORY ] to display the Job No. Selection Screen. Job No.
Page 239: Job Memory Form
Section 10 : Job Memory Job Memory Form Make a copy of this form to record frequently-used copy jobs stored in Job Memory. Update the information when changes are made. Make additional copies, as needed. JOB NUMBER/NAME JOB DESCRIPTION Job Recall Job Memory Form Memory...
Page 240 Section 10 : Job Memory Job Memory Form (continued) JOB NUMBER/NAME JOB DESCRIPTION 10 - 6...
Page 241: Section 11: Server Function
Section 11: Server Function Server Function Image Store/Delete Mode To Store Image Data in HDD/PC To Transmit Image Data to PC To Delete Image Data Image Store & Output Mode Image Recall Mode Image Edit Mode Server Function Image Store/Delete Image Store&Output Image Recall...
Page 242: Server Function
Section 11 : Server Function Server Function Use the Server function with HDD to accumulate scanned images into built-in DIMM (memory), then store the image data in HDD* (option) so that the data can be recalled to DIMM, and then output as needed. This function also allows storing the image data in normal copying procedure.
Page 243: Image Store/Delete Mode
Section 11 : Server Function Image Store/Delete Mode When the original image is stored into DIMM, use this function to store the image data into the HDD/PC. In the event data is already stored in the HDD/PC, use this function to transmit it from HDD to PC or delete it from HDD/PC.
Page 244 Section 11 : Server Function Image Store/Delete Mode (continued) To Store Image Data in HDD/PC (continued) 4 Enter the desired image data password in up to 8 characters from the touch screen keypad. To correct an entry, touch 1-CHARACTER DELETE repeatedly to delete each character, then enter the correct password.
Page 245 Section 11 : Server Function Image Store/Delete Mode (continued) To Store Image Data in HDD/PC (continued) 8 Position original(s) FACE UP in the document feeder or FACE DOWN on the platen glass. When using Platen store mode, see p. 6-29 to p. 6-31. When using RADF store mode, see p.
Page 246: To Transmit Image Data To Pc
Section 11 : Server Function Image Store/Delete Mode (continued) To Transmit Image Data to PC Procedure 1 Press [ MODE ] to light up the [ SCANNER/SERVER ] LED. The Scanner/Server Setting Menu Screen will be displayed. 2 Touch IMAGE STORE/DELETE to display the Image Data Store/Delete Site Selection Screen.
Page 247 Section 11 : Server Function Image Store/Delete Mode (continued) To Transmit Image Data to PC (continued) 6 Touch the desired job name key to highlight it, then touch OK . At this time, the Image Data Transmitting Screen displays without the data transmission actually started.
Page 248: To Delete Image Data
Section 11 : Server Function Image Store/Delete Mode (continued) To Delete Image Data Procedure 1 Press [ MODE ] to light up the [ SCANNER/SERVER ] LED. The Scanner/Server Setting Menu Screen will be displayed. 2 Touch IMAGE STORE/DELETE to display the Image Data Store/Delete Site Selection Screen.
Page 249 Section 11 : Server Function Image Store/Delete Mode (continued) To Delete Image Data (continued) 5 If the password is correct, touch OK to display the Job Name Entry Screen. 6 Touch the ▲ or ▼ key on the right side of the job name list to highlight the data to be deleted, then touch JOB DELETE .
Page 250: Image Store & Output Mode
Section 11 : Server Function Image Store & Output Mode Use this function to store the scanned image data in HDD after copying is completed. This storing function does not conflict with any other copying conditions. NOTE: Installation of the optional HDD (HD-102) is required for this function. With the HDD installed, the HDD STORE key will be displayed on the Finisher Mode Selection Screen (for machine with Finisher installed) or on the Output Menu Screen (for machine without Finisher).
Page 251 Section 11 : Server Function Image Store & Output Mode (continued) 4 If the password is correct, touch OK to display the Job Name Entry Screen. Enter the desired job name in up to 8 characters from the touch screen keypad. To correct an entry, touch 1-CHARACTER DELETE repeatedly to delete each character, then enter the correct job name.
Page 252 Section 11 : Server Function Image Store & Output Mode (continued) 9 After scanning all the originals, the Image Data Storing Screen will be displayed. The machine automatically starts to store the data in HDD. The Basic Screen will resume when completed. Image Data Storing Screen NOTE: To suspend the storing job, touch CANCEL on the Image Data Storing Screen, then touch YES...
Page 253: Image Recall Mode
Section 11 : Server Function Image Recall Mode Use this function to recall the image data stored in HDD/PC to built-in DIMM for printing. NOTES: • Installation of the optional HDD (HD-102) is required to recall data from the HDD. •...
Page 254 Section 11 : Server Function Image Recall Mode (continued) 5 If the password is correct, touch OK to display the Recall Job Selection Screen. 6 Touch the desired job name key to highlight it, then touch a to move it to the recall list on the right side.
Page 255: Image Edit Mode
Section 11 : Server Function Image Edit Mode Use this function to transmit a scanned image data to PC to edit it, and return the edited data to DIMM for printing. NOTE: To use this mode, the machine should be connected to PC by cross-cable, or with network provided that a specific software for using Server function is installed in PC.
Page 256 Section 11 : Server Function Image Edit Mode (continued) 6 Press [ START ] to scan. After scanning is completed, the Image Data Edit Screen will be displayed to indicate that the scanned image data is ready for transmission. Image Data Edit Screen NOTE: To stop the Image Edit operation while the Image Data Edit Screen is displayed, touch EXIT.
Page 257: Section 12 : Key Operator Mode
Key Operator Mode Section 12 : Key Operator Mode Function Menu Map System Initial Key Operator Mode Setting How to Access the Key Operator Mode Copier Initial Setting Function Menu Map User Setting System Initial Setting [1] Mode Date & Time Setting [1] Language Select Setting [2] IP Address Setting [3] Lock/Delete...
Page 258: Key Operator Mode
Section 12 : Key Operator Mode Key Operator Mode The key operator is trained to handle all special key operator functions that are not accessible to the general user, such as monitoring overall copier activity, machine performance, and service information; modifying machine settings; and controlling user activity, for billing purposes.
Page 259: How To Access The Key Operator Mode
Section 12 : Key Operator Mode Key Operator Mode Key Operator Mode (continued) How to Access the Key Operator Mode Procedure 1 Press the [ HELP ] button on the Control panel to display the Help Screen. 2 Then, touch the Key Operator Mode on the Help Screen. The Key Operator Password Entry Screen displays when the 4-digit key operator password is set by service.
Page 260: Function Menu Map
Section 12 : Key Operator Mode Function Menu Map FUNCTION MENU SUB FUNCTION MENU AND SETTING OPTIONS [1] System initial [1] Date&Time setting: [Present time; Setting time; Summer time] setting [2] Language select setting: [Japanese; English] [3] IP address setting: [IP address; Subnetmask; Gateway address; Line speed] [2] Copier initial Copy mode: [RADF;...
Page 261 Section 12 : Key Operator Mode Menu Map (continued) Function Menu Map FUNCTION MENU SUB FUNCTION MENU AND SETTING OPTIONS [12] Power save Auto low power: [5, 10, 15, 30, 60, 90, 120, 240] setting Auto shut off: [—, 30, 60, 90, 120, 240] [13] Memory switch [1] Auto reset timer [2] AUTO RESET key function...
Page 262 Section 12 : Key Operator Mode Function Menu Map (continued) FUNCTION MENU SUB FUNCTION MENU AND SETTING OPTIONS [14] Machine management [1] Job memory list list print [2] User management list [3] E.K.C. management list [4] Font pattern list [15] Call remote centre [1] Call for JAM concerns [2] Call for SC concerns [3] Toner bottle supply call...
Page 263: System Initial Setting [1]
Section 12 : Key Operator Mode System Initial Setting [1] Function Menu Map Set the following initial conditions of the copier. System Initial • Date & Time setting: Current date and time, summer time Setting • Language select setting: Language used in LCD (English) •...
Page 264: Language Select Setting [2]
Section 12 : Key Operator Mode System Initial Setting [1] (continued) Language Select Setting [2] Select the language used in the LCD (English). ❒ Default setting: English System Initial Setting Menu Screen Language Selection Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 265: Ip Address Setting [3]
Section 12 : Key Operator Mode System Initial Setting [1] (continued) IP Address Setting [3] System Initial Setting When using the Job Editor function, this setting is required to enable a PC to gain access to this machine. NOTE: Ask your network manager to perform this setting. Incorrect setting may cause a trouble in other network systems.
Page 266: Copier Initial Setting [2]
Section 12 : Key Operator Mode Copier Initial Setting [2] Initial settings are the settings that display automatically when the copier is powered on, when Auto/Reset timer is operated, or when [ AUTO RESET ] key is pressed. These settings can be changed by the key operator, as shown in this section.
Page 267 Section 12 : Key Operator Mode Copier Initial Setting [2] (continued) Key Operator Mode Screen Copier Initial Setting Screen Copier Initial Setting Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 268: User Setting Mode [3]
Section 12 : Key Operator Mode User Setting Mode [3] Set two userset density levels and three USERSETs of magnification. User Density Level 1 Setting [1] Output copying samples from 16 density levels from Lighter to Normal or Normal to Darker, then select the desired exposure and program it as USER 1.
Page 269: User Density Level 2 Setting [2]
Section 12 : Key Operator Mode User Setting Mode [3] (continued) User Density Level 2 Setting [2] Output copying samples from 16 density levels from Lighter to Normal or Normal to Darker, then select the desired exposure and program it as USER 2. The programmed copy density can be recalled by selecting USER 2 on the Basic Screen.
Page 270: User Lens Mode Ratio Setting [3]
Section 12 : Key Operator Mode User Setting Mode [3] (continued) User Lens Mode Ratio Setting [3] The preset and userset ratios are used to reduce and enlarge the original image to accommodate copy paper size, and are available on the Basic Screen. Normally, users are allowed to change the three USERSET s in the bottom line on the User Lens Mode Ratio Setting Screen.
Page 271: Electronic Key Counter) Function Setting [4]
Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] This function can only be accessed by the key operator after a 8-digit EKC master key code is entered. The Electronic Key Counter allows you to monitor all copying activity by controlling EKC password accounts.
Page 272: How To Access The Ekc Setting Mode
Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) How to Access the EKC Setting Mode Key Operator Mode Screen EKC Master Key Code Screen EKC Setting Menu Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 273: Data Edit [1]
Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) E.K.C. Data Edit [1] Use this setting to display the list of copy count and copy limit for each account, to change, add, or delete the EKC data, and to reset the copy count of the individual account. ❒...
Page 274 Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) E.K.C. Data Edit [1] (continued) 4 Touch [1] E.K.C. data edit . The EKC Data Edit Screen will be displayed. To change, add, or delete the EKC data, and to reset the copy count of the individual account, follow the procedure for each as described below.
Page 275 Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) E.K.C. Data Edit [1] (continued) To Delete EKC Data: (1) Touch ▲ or ▼ key on the right side of the list to highlight the EKC data to be deleted, then touch Delete .
Page 276: All Count Reset [2]
Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) E.K.C. All Count Reset [2] Reset the count for all EKC accounts. EKC Setting Menu Screen EKC All Count Reset Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 277: Function Setting [3]
Section 12 : Key Operator Mode E.K.C. (Electronic Key Counter) Function Setting [4] (continued) E.K.C. Function Setting [3] Use this function to turn EKC On or Off, or to select whether the machine will stop when the count limit is reached, or if the copier will complete the copy job before stopping when reaching maximum copy count.
Page 278: Lock/Delete Job Memory [5]
Section 12 : Key Operator Mode Lock/Delete Job Memory [5] Use this function to lock/unlock or delete a Job that has been programmed. A locked Job is indicated by a lock icon ( ) on the Lock/Delete Job Memory Screen. The settings of a locked job cannot be changed.
Page 279: Paper Type / Special Size Set [6]
Section 12 : Key Operator Mode Paper Type / Special Size Set [6] Use this function to indicate a specific paper type or to specify a special paper size for each tray key on the Basic Screen. This is especially useful when special paper is used on a regular basis and is always placed in a specific paper tray.
Page 280 Section 12 : Key Operator Mode Paper Type / Special Size Set [6] (continued) To specify special size; (1) Touch Special size setting on the Paper Type Setting Screen to display the Special Size Setting Screen. (2) Touch the desired paper tray to highlight it. (3) Touch a paper size key to specify a paper size for the selected tray.
Page 281: Panel Contrast / Key Sound Adjustment [7]
Section 12 : Key Operator Mode Panel Contrast / Key Sound Adjustment [7] Use this feature to adjust the level of brightness of the touch screen portion of the control panel, and also the volume of the touch key. Key Operator Mode Screen Panel Contrast/ Key Sound Adjustment Screen Paper Type/ Special Size...
Page 282: Key Operator Data Setting [8]
Section 12 : Key Operator Mode Key Operator Data Setting [8] Use this screen to enter the name and extension number of the key operator indicated on the Help Screen developed from the Basic Screen. ❒ Setting options: 5-digit key operator telephone extension; Max. 8-character key operator name Key Operator Mode Screen Key Operator Data Setting Screen...
Page 283: Weekly Timer [9]
Section 12 : Key Operator Mode Weekly Timer [9] This function can be accessed only by the key operator after a unique 4-digit Weekly timer master key code is entered. The Weekly Timer is a copier management function that shuts down power to the machine on a daily or hourly basis, and can be programmed specifically for lunch breaks, weekends and holidays, or any time the copier is not required.
Page 284: How To Access The Weekly Timer Setting Mode
Section 12 : Key Operator Mode Weekly Timer [9] (continued) How to Access the Weekly Timer Setting Mode Key Operator Mode Screen Weekly Timer Master Key Code Screen Weekly Timer Setting Menu Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 285: Weekly Timer On/Off Setting [1]
Section 12 : Key Operator Mode Weekly Timer [9] (continued) Weekly Timer On/Off Setting [1] Weekly Timer Setting Menu Screen Weekly Timer On/Off Setting Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 286: Timer Setting [2]
Section 12 : Key Operator Mode Weekly Timer [9] (continued) Timer Setting [2] Use this function to set the On/Off times in hours and minutes for each day of the week or set the collective time for the entire week, i.e., the same On/Off time for each day. Weekly Timer Setting Menu Screen Weekly Timer On/Off Time Setting Screen Weekly Timer On/Off Time Block Setting Screen...
Page 287 Section 12 : Key Operator Mode Weekly Timer [9] (continued) Timer Setting [2] (continued) 6 When you open this screen, the ON and OFF times are always set at 00:00~00:00. Touch to highlight the day(s) of the week to be set. More than one can be selected at a time.
Page 288: Timer Action On/Off Setting [3]
Section 12 : Key Operator Mode Weekly Timer [9] (continued) Timer Action On/Off Setting [3] Use this function to set the On/Off condition of the copier for a given month. Set the On- Off condition for specific days; or collectively, for all Mondays through Sundays of the given month.
Page 289 Section 12 : Key Operator Mode Weekly Timer [9] (continued) Timer Action On/Off Setting [3] (continued) 7 Touch OK on the Timer Action On/Off Setting Screen to complete the setting and return to the Weekly Timer Setting Menu Screen. 8 If other Weekly timer settings are required, select another desired menu item, from [1]~[5].
Page 290: Lunch Hour Off Setting [4]
Section 12 : Key Operator Mode Weekly Timer [9] (continued) Lunch Hour Off Setting [4] The Weekly timer function turns the copier ON and OFF once a day. Use this Lunch hour off function to shut down power for lunch break then turn on again while the copier is turned on due to the Weekly timer function.
Page 291: Timer Interrupt Password Setting [5]
Section 12 : Key Operator Mode Weekly Timer [9] (continued) Timer Interrupt Password Setting [5] Use this password setting mode to establish a 4-digit password requirement for using Timer Interrupt function. The default password of 0000 allows the timer function to be interrupted without the requirement for password entry.
Page 292: Control Panel Adjustment [10]
Section 12 : Key Operator Mode Control Panel Adjustment [10] Use this feature to check the malfunction of the LCD touch screen due to the shift in position of the touch sensor. Key Operator Mode Screen Control Panel Adjustment Screen Procedure 1 Press [HELP] to display the Help Screen, then touch Key Operator Mode .
Page 293: Tray Size Setting [11]
Section 12 : Key Operator Mode Tray Size Setting [11] Select to be detected or not to be detected, and priority of detection for each tray when ATS/APS functions. Key Operator Mode Screen 1 Key Operator Mode Screen 2 Tray Auto Select Setting Screen Control Panel Adjustment Tray Size...
Page 294: Power Save Setting [12]
Section 12 : Key Operator Mode Power Save Setting [12] Select the interval of time that must elapse before Auto Low Power and Auto Shut Off become activated. Auto Shut Off conserves more energy than Auto Low Power. The period of time selected for Auto Low Power cannot exceed the Auto Shut Off setting. Key Operator Mode Screen 1 Key Operator Mode Screen 2 Power Save Setting Screen...
Page 295: Memory Switch Setting [13]
Section 12 : Key Operator Mode Memory Switch Setting [13] This function allows you to change the Memory Settings listed below. See pp. 12-41~12- 43 for details on Memory Settings. SW No. Item Setting (default is underlined) No. 01: Auto reset timer OFF/ 30 sec./ 60 sec./ 90 sec./ 120 sec./150 sec./ 180 sec./ 210 sec./ 240 sec./ 270 sec./ 300 sec.
Page 296 Section 12 : Key Operator Mode Memory Switch Setting [13] (continued) No. 41: Trimmer (STD/ Non STD size) STD size/ Non STD size No. 42: Timer which prohibits Printer OFF/ 15 seconds/ 30 seconds/ 60 seconds/ 90 seconds No. 43: Bookmark function ON (It is cancel every JOB)/ ON (It is not cancel every JOB)/ OFF No.
Page 297 Section 12 : Key Operator Mode Memory Switch Setting [13] (continued) The following functions can be provided by the Memory switch settings. [1] Auto reset timer Set the reset interval starting from the completion of a copying job until the machine returns to the initial condition.
Page 298 Section 12 : Key Operator Mode Memory Switch Setting [13] (continued) [14] Select tray when APS cancel Select the tray to be automatically selected when APS is released. [15] Platen original size detect Select the series of the original paper size detected from the platen glass. [16] RADF original size detect Select the series of the original paper size detected from the RADF.
Page 299 Section 12 : Key Operator Mode Memory Switch Setting [13] (continued) [31] Auto select of Booklet copy Set the copier with FS-108BM mounted to automatically select the Booklet mode when Stapling & Folding or Folding output mode is selected. [32] E.K.C. password Select the acceptable number of digits for the EKC master key code.
Page 300: Machine Management List Print [14]
Section 12 : Key Operator Mode Machine Management List Print [14] Use this function to print out the list selected from the following items. • Job memory list: Programmed contents of Job memory • User management list: Home position settings selected by user •...
Page 301: Call Remote Centre [15]
Section 12 : Key Operator Mode Call Remote Centre [15] When activated, the Remote Diagnostics option is automatically monitored by a Konica service representative. In case of machine trouble, select the Call Remote Centre option. Your service representative will contact you to determine the appropriate means for resolving the problem.
Page 302: Side 2 Lens Adjustment [16]
Section 12 : Key Operator Mode Side 2 Lens Adjustment [16] Use this function to set the adjustment data of the magnification ratio for each tray as Side Key Operator Mode Screen 2 Side 2 Lens Adjustment Screen Procedure 1 Press [ HELP ] to display the Help Screen, then touch Key Operator Mode . Enter a 4-digit key operator password, then touch OK to display the Key Operator Mode Screen.
Page 303: Finisher Adjustment [17]
Section 12 : Key Operator Mode Finisher Adjustment [17] Use this mode to make fine adjustments to each function of the finisher. Key Operator Mode Screen 2 Finisher Adjustment Menu Screen Stapling&Folding Stopper Position Adjustment Screen Folding Stopper Position Adjustment Screen Trimming Stopper Adjustment Screen Punch Adjustment Menu Screen Punch Vertical Position Adjustment Screen...
Page 304: Hdd Management Setting [18]
Section 12 : Key Operator Mode HDD Management Setting [18] Use this function to manage the image data stored in the optional HDD (HD-102) and to check the space available for new data. • Password list/delete: Display the password list on the screen, or delete the image data (JOB) by deleting the corresponding password from the list.
Page 305 Section 12 : Key Operator Mode HDD Management Setting [18] (continued) To view the password list or delete the password and the corresponding image data: (1) Touch [1] Password list/delete to display the Password List/Delete Screen. (2) Touch to highlight the password key to be deleted, then touch DELETE . The popup menu will appear for confirmation.
Page 306: Key Operator Ekc Form
Section 12 : Key Operator Mode Key Operator EKC Form ACCT No. PASSWORD COUNT/LIMIT 12 - 50...
Page 307: Section 13: Maintenance & Supplies
Section 13: Maintenance & Supplies Loading Paper Paper Indicator Paper Empty Indicator Using the HELP Key Loading Paper in Tray 1, 2, and 3 Loading Paper in Tray 4 (LT-401/LT-411) Loading Tabbed Sheets in Tray 1, 2, or 3 Loading Tabbed Sheets in Tray 4 (LT-401/LT-411) Adding Toner Inserting a New Staple Cartridge into FS-108/108BM Finisher Empty Waste Basket of TU-108 Trimmer Unit...
Page 308: Loading Paper
Section 13 : Maintenance & Supplies Loading Paper Paper Indicator ( A paper indicator always appear on each tray key of the Basic Screen to indicate the paper level of the tray. Basic Screen Paper Empty Indicator ( When a paper tray becomes empty, paper empty indicator flashes on the tray key to prompt you to supply paper.
Page 309: Loading Paper In Tray 1, 2, And 3
Section 13 : Maintenance & Supplies Loading Paper (continued) Loading Paper in Tray 1, 2, and 3 Be sure to load the paper type specified on the tray key of the Basic Screen; otherwise mishandled paper may occur. When lading paper into the tray specified as TAB, see p. 13-5. Procedure 1 Withdraw tray 1, 2, or 3, and place paper on the tray with the curl side turning up.
Page 310: Loading Paper In Tray 4 (Lt-401/Lt-411)
Section 13 : Maintenance & Supplies Loading Paper in Tray 4 (LT-401/LT-411) Be sure to load the paper type specified on the tray key of the Basic Screen; otherwise mishandled paper may occur. When lading paper into the tray specified as TAB, see p. 13-6. LT-401 LT-411 Procedure...
Page 311: Loading Tabbed Sheets In Tray 1, 2, Or 3
Section 13 : Maintenance & Supplies Loading Paper (continued) Loading Tabbed Sheets in Tray 1, 2, or 3 Load offset tabbed sheets so that the tab extensions are on the left at the rear (not front) of the tray. The tab extension width should be 12.5 mm or less. When loading tabbed sheets in the tray, be sure to specify the paper type as TAB in the Key operator mode;...
Page 312: Loading Tabbed Sheets In Tray 4 (Lt-401/Lt-411)
Section 13 : Maintenance & Supplies Loading Tabbed Sheets in Tray 4 (LT-401/LT-411) Load offset tabbed sheets so that the tab extensions are on the right at the rear (not front) of the tray. The tab extension width should be 12.5 mm or less. When loading tabbed sheets in the tray, be sure to specify the paper type as TAB in the Key operator mode;...
Page 313: Adding Toner
Section 13 : Maintenance & Supplies Adding Toner When toner supply is low, “ADD TONER” icon displays on the touch screen. Add toner according to the procedure as follows. Basic Screen CAUTION Keep the toner bottle away from children. The toner is nontoxic; however if you inhale or contact with eyes by accident, flush with water and seek medical advice.
Page 314 Section 13 : Maintenance & Supplies Adding Toner (continued) 4 Shake the new toner bottle several times to loosen toner, then remove the toner bottle cap. 5 Set the new toner bottle into the toner unit. 6 Align the hollow part on the toner bottle with the ▼ mark on the toner unit. 7 Push the toner bottle lock lever backward until it stops.
Page 315: Inserting A New Staple Cartridge Into Fs-108/108Bm Finisher
Follow the procedure below to remove the empty cartridge from the finisher cartridge housing and set the new cartridge . Use only the staples supplied by Konica. Contact your service centre to reorder. Procedure 1 Open the Finisher door.
Page 316 Section 13 : Maintenance & Supplies Inserting a New Staple Cartridge into FS-108/108BM Finisher (continued) 5 Insert the new cartridge into the housing. NOTE: Do not remove the remaining staples inside the housing; otherwise, the first sheet output after the replenishment will not be stapled.
Page 317: Empty Waste Basket Of Tu-108 Trimmer Unit
Section 13 : Maintenance & Supplies Empty Waste Basket of TU-108 Trimmer Unit When the waste basket becomes full, “Waste basket of Trimmer is full / Please empty waste basket” message displays on the touch screen. Procedure 1 Open the trimmer front door. Withdraw the waste basket.
Page 318: Empty Waste Basket Of Pu-108/Pz-108 Punching (/Z-Folding) Unit
Section 13 : Maintenance & Supplies Empty Waste Basket of PU-108/PZ-108 Punching (/Z-Folding) Unit When the waste basket becomes full, “Waste basket of Punching unit is full / Please empty waste basket” message displays on the touch screen. Procedure 1 Open the Finisher/Punching (/Z-Folding) unit front door.
Page 319: Preventive Maintenance
Section 13 : Maintenance & Supplies Preventive Maintenance After a set number of copies have been made on your copier, Preventive Maintenance (PM) will be required for maintaining optimal performance. When preventive maintenance is due, a message will prompt you to contact your service centre for maintenance.
Page 320: Cleaning The Left Partition Glass
Section 13 : Maintenance & Supplies Cleaning the Left Partition Glass The glass partition at the far left of the platen glass is designed for real-time scanning from the RADF. Keep this glass clean; otherwise soil marks may be copied, resulting in dark lines on the copies.
Page 321: Section 14: Troubleshooting
Section 14: Troubleshooting Call for Service Limited Use of the Copier in Trouble Memory Overflow Power OFF/ON Screen Clearing Mishandled Paper Copying Hints Call for Service Memory Overflow Power OFF/ON Screen Cleaning Mishandled Paper Copying Hints T rouble- shooting...
Page 322: Call For Service
1 Immediately make note of the Report code No. indicated in the upper portion of the screen. 2 Turn OFF the main power switch. 3 Unplug the machine. 4 Contact your Konica service centre and report the condition and code No. 14 - 2...
Page 323: Limited Use Of The Copier In Trouble
ADU that are not affected by the trouble. To obtain this limited functionality of the copier, consult your Konica service centre. Be sure to utilize the limited function only temporarily, and arrange for machine repair immediately.
Page 324: Memory Overflow
Section 14 : Troubleshooting Memory Overflow In certain modes, the Konica 7075 uses memory for convenience and to make operations flow smoothly. Occasional memory overflow may occur if the installed memory is inadequate for the copy conditions selected. Should memory overflow occur frequently, it is recommended that you contact your Konica service centre to extend the memory capacity in your machine.
Page 325: Power Off/On Screen
Section 14 : Troubleshooting Power OFF/ON Screen When any trouble affects the electric signal of the copier, the Power OFF/ON Screen will be displayed. Turn OFF then ON the power switch. Power OFF/ON Screen Memory Overflow Power OFF/ON Screen T rouble- T rouble- shooting shooting...
Page 326: Clearing Mishandled Paper
Section 14 : Troubleshooting Clearing Mishandled Paper CAUTION When removing mishandled paper, be sure to leave no torn paper inside the machine, avoid touching the drum or scratching it in any way, and keep all metal and magnetic objects, e.g., watches, jewelry, etc. away from the drum area. When a paper misfeed occurs, the copier stops making copies and mishandled paper codes display on the screen to indicate misfeed area(s).
Page 327 Section 14 : Troubleshooting Clearing Mishandled Paper (continued) CAUTION: The right rear area of the conveyance fixing unit generates high voltage. If touched, electrical shock may occur. DO NOT TOUCH! CAUTION: The fixing unit is internally very hot. To avoid getting burned DO NOT TOUCH the area. Use care when withdrawing the conveyance fixing unit, and remove the mishandled paper in the fixing unit.
Page 328: Copying Hints
Section 14 : Troubleshooting Copying Hints COPIER DOES NOT OPERATE WHEN POWER SWITCH IS ON Fully insert paper trays. Close RADF. Be sure power plug is firmly inserted in electrical socket. COPY IMAGE IS TOO LIGHT Manually adjust copy density to darker density. Check toner indicator and add toner, if required.
Page 329 Section 14 : Troubleshooting Copying Hints (continued) COPYING DOES NOT RESUME AFTER MISHANDLED PAPER IS REMOVED Check copier diagram on touch screen for additional indications of mishandled paper. COPY QUALITY IS POOR Check paper for dampness, and replace if necessary. THE ORIGINAL PAPER IS MISHANDLED OR SKEWED IN THE DOCUMENT FEEDER Originals should conform to the recommended size and weight.
Page 330 If this message continues to display after selecting paper size, select 1.00 magnification, even if it is already indicated, then press [ START ]. If desired, ask your Konica service centre to enable the machine to default to 1.00 magnification in this situation.
Page 331: Section 15: Machine Specifications
Section 15: Machine Specifications Main Body Specifications Main Body RADF (DF-313) Option Specifications FS-108/108BM In-Bin Stapler Finisher Cover Sheet Feeder (PI-108) Trimmer Unit (TU-108) Punching Unit (PU-108) Punching / Z-Folding Unit (PZ-108) Large Capacity Tray (LT-401) Large Capacity Tray (LT-411) Memory Unit Image Processor (IP-601) HDD (HD-102)
Page 332: Main Body Specifications
Section 15 : Machine Specifications Main Body Specifications Main Body Name: Konica 7075 Type: Console type Transfer method: Indirect electrostatic method Platen glass: Fixed Light-sensitive unit: Light source: Xenon lamp (280W) Developing method: Dry, 2-component magnetic brush developing Fixing method:...
Page 333: Radf (Df-313)
Section 15 : Machine Specifications Main Body Specifications (continued) Main Body (continued) Effective size: 1311(W) x 865(D) mm (main body + RADF) 2144(W) x 865(D) mm (main body + RADF + FS-108/108BM + LT-401) 3180(W) x 865(D) mm (main body + RADF + FS-108BM + TU-108 + LT-411) 3349(W) x 865(D) mm (main body + RADF + FS-108BM + PU-108/ PZ-108 + TU-108 + LT-411)
Page 334: Trimmer Unit (Tu-108)
Section 15 : Machine Specifications Option Specifications (continued) Trimmer Unit (TU-108) Function: Trimming the end of booklet Types of paper: 60 to 90 g/m paper One cover paper only (91 to 200 g/m paper) Paper sizes: A3, B4, A4R, 8.5"x11"R Number of trimmed sheet: 3 sheets max.
Page 335: Large Capacity Tray (Lt-401)
Section 15 : Machine Specifications Option Specifications (continued) Large Capacity Tray (LT-401) Function: Paper feed into main body Types of paper: A4, 8.5"x11" (50 to 200 g/m paper) Dimensions: 430(W) x 639(D) x 690(H) mm Weight: Approx. 30 kg Power source: Supply from main body Large Capacity Tray (LT-411) Function:...
Page 336: Copy Materials
Section 15 : Machine Specifications Copy Materials Maintenance Kit Developer Cleaning blade Collection roller ass’y Cleaner idler gear Fixing cleaning roller Fixing roller (D) Pad ass’y Filter (K) Dustproof filter ass’y Charging cleaning block/A ass’y Charging cleaning block/B ass’y Charging control plate Charging wire Discharge wire Transfer cleaning block ass’y (Upper)
Page 337 Index...
Page 338 Index NUMBER Control Panel Adjustment 12-36 Control panel contrast key 6-43 180° Rotation 6-36 Copier counter 5-8 2 in 1 key 9-13 Copier Initial Setting 12-10 2 Repeat 9-39 COPY INSERT key 9-7 4 in 1 key 9-13 Copy Mode 6-5 4 Repeat 9-39 Copy sheet interleaving 9-20 600 Dpi 8-7...
Page 339 Index Manual staple control panel 3-5 Manual Stapling 7-23 HDD 11-2 Memory indicator 6-2 HDD Management Setting 12-48 Memory Overflow 14-4 HDD STORE key 11-10 Memory Switch Setting 12-39 HELP key 6-43 Mixed Original 8-12 HELP MENU key 6-43 MODE key 3-8 Help Mode 6-43 Multi-sheet bypass tray 6-44 High Mode 8-3...
Page 340 Index Touch Screen 3-9 Tray Size Setting 12-37 RADF (Reversing Automatic Document Feeder) 3-3 Trimmer stacker 3-6 RADF AMS 12-42 Trimmer stacker cover 3-6, 7-15, 7-24, 9-18 RADF APS 12-41 Trimmer unit 3-3, 3-6 RADF frame erasure selection 12-41 Trimmer unit tray 3-6 RADF Store Mode 6-32 Trimming mode 7-13 RE key 6-15...
Page 342 Recycled paper is used for the inside pages of this manual. MANUFACTURER • ONICA CORPORATION • TOKYO JAPAN 2001. 11 m Printed in Japan...

Konica Minolta 7075 Instruction Manual

Operation

Output Modes

Maintenance & Supplies

Quick Links

Related Manuals for Konica Minolta 7075

Summary of Contents for Konica Minolta 7075
