Other Programming Selections

•
Clear One Data Format
This deletes one data format for one symbology. If you are clearing the primary
format, scan 0. If you are clearing an alternate format, scan 1, 2, or 3, depending on
the alternate format you are clearing. Scan the Terminal Type (see the "Terminal
Interface Selections" in Chapter 2), Code ID, and the length of the format you want
to delete. That length data format for that symbology is deleted and all other formats
are unaffected.
•
Save/Discard
Save exits and saves any Data Format changes. Discard exits without saving any
Data Format changes.

Format Editor Commands

Send Commands

F1 Send all characters followed by "xx" key or function code, starting from current
cursor position. Syntax = F1xx (xx stands for the hex value for an ASCII code. See
the "Hex to ASCII Conversion Chart" earlier in this chapter.)
F2 Send "nn" characters followed by "xx" key or function code, starting from current
cursor position. Syntax = F2nnxx (nn stands for the numeric value (00-99) for the
number of characters and xx stands for the hex value for an ASCII code.)
F3 Send up to but not including "ss" character (Search and Send) starting from current
cursor position, leaving cursor pointing to "ss" character followed by "xx" key or
function code. Syntax = F3ssxx (ss and xx both stand for the hex values for ASCII
codes.)
F4 Send "xx" character "nn" times (Insert) leaving cursor in current cursor position.
Syntax = F4xxnn (xx stands for the hex value for an ASCII code, and nn is the
numeric value (00-99) for the number of times it should be sent.)
E9 Send all but the last "nn" characters, starting from the current cursor position.
Syntax = E9nn (nn is the numeric value (00-99) for the number of characters that
will not be sent at the end of the message.)
