Sabre 1552 Scanner and MicroBar 9745 Base Station System Manual
The following illustration shows the breakdown of a message string:
Points to Keep in Mind
•
•
•
•
•
To add a prefix or suffix
1. Scan the Add Prefix or Add Suffix bar code.
2. Determine the two-digit hex value from the Symbology Chart later in this chapter
3. Scan the two hex digits from the "Programming Chart" in Appendix A or scan 9, 9
4. Determine the hex value from the Hex to ASCII Conversion Chart later in this
4-10
Prefix Scanned data
1-12 alpha Variable
numeric length
characters
1552S017.eps
It is not necessary to build a message string. The selections in this chapter are only
used if you wish to alter the default settings.
Default prefix = None. Default suffix = Carriage Return.
A prefix or suffix may be added or cleared from one symbology or all symbologies.
You can add any prefix or suffix from the Hex to ASCII Conversion Chart later in
this chapter, plus Code ID and AIM ID.
You can string together several entries for several symbologies at one time.
Enter prefixes and suffixes in the order in which you want them to appear on the
output.
Add Prefix
Add Suffix
for the symbology to which you want to apply the prefix or suffix.
for all symbologies.
chapter for the prefix or suffix you wish to enter.
Suffix
1-12 alpha
numeric
characters
