Auxiliary RS-232/Wand Emulation Connector

The auxiliary RS-232/scanner connector supports wand emulation or the attachment of
an RS-232 input device. The auxiliary port is compatible with all Intermec contact and
non-contact bar code scanners, including bar code contact wands, lasers, and CCDs
which operate in RS-232 (both TTL and True).
Aux RS-232 Connector: 10-Pin Modular Receptacle
Pin
1
2
3
4
5
6
7
8
9
10
Communication Parameters for Auxiliary RS-232 Port
Start Bit 1
Data Bits 7 or 8
Stop Bits 1 or 2
Parity None, Mark, Space, Odd, or Even
Baud Rate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400
When the base is configured for wand emulation, the auxiliary port will output wandem
data on Pin 7 at the selected rates/polarity.
Specifications and Factory Defaults
Signal Name Description
GND Power/Signal Ground
TXD Transmit Data (output)
RXD Receive Data (input)
RTS Request to Send (output)
CTS Clear to Send (input)
VCC 5 Volt DC Power Out
WANDEM TTL Wand Data (output)
VIN AUX Power into Aux
VIN FLASH 12V Flash Radio (input)
N/C No connection
