IBM 4683 Async Address Selections

If you are going to program the interface for IBM 4683 Async Addresses, you must first
program the Terminal ID as 51 (see "Terminal Interface Selections" in Chapter 2).
Then, scan one of the programming codes below for your 4683 Async Address
selection. When using any of the IBM 4683 interfaces, the maximum allowable data
rate into the base auxiliary port is 9600 baud.
Address $68
(Socket 23: 2A Left)
Address $69
(Socket 23: 2B Right)
Address $64
(Socket 25: 2A Left)
Address $65
(Socket 25: 2B Right)
Aux Port Disable
3-12
