Quick Start and Interface Menu

IBM 468X/9X Ports 5B, 9B, and 17 Interface

Scan one of the following "Plug and Play" bar codes to program the interface for IBM
4683 Port 5B, 9B, or 17.
Note: When using any of the IBM 4683 interfaces, the maximum allowable data rate
into the base aux port is 9600 baud.
IBM 468X/9X Port 5B Interface
IBM 468X/9X Port 9B HHBCR-1 Interface
IBM 468X/9X Port 9B HHBCR-2 Interface
IBM 468X/9X Port 17 Interface
Industrial Interface (1700, 5900 Terminals), Aux Port:
Wand Emulation Black High
Wand Emulation (Code 39 Format) Interface
1
Wand Emulation (Same Code Format) Interface
1
Supports Code 39, UPC, EAN, Code 128, Interleaved 2 of 5, and Codabar. All other bar codes output as Code 39.
