Sabre 1552 Scanner and MicroBar 9745 Base Station System Manual
Aux Data Formatter Example
Five digit data is sent to the auxiliary port; however, the host system can only accept
eight digit data. Three zeroes must be added to the beginning of the auxiliary port data.
Received
12345
Refer to the Aux Format Editor Commands in the next section and the "Programming
Chart" in Appendix A to format the following example:
1. Scan the Enter Aux Data Format bar code.
2. Scan 0 9 9 (all terminal types).
3. Scan 7 2 (the hex value for the auxiliary port).
4. Scan 0 0 0 5 (the data length).
The Aux Data Editor Commands are:
1. Scan F 4.
2. Scan 3 0 (hex value for 0).
3. Scan 0 3 (indicating the 0 should be sent 3 times).
4. Scan F 1 to send the data, then 0 0 (the hex value for NUL).
5. Scan Save to end the Aux Data Formatting.

Aux Format Editor Commands

Send Commands
F1 Send all characters followed by "xx" key or function code, starting from current
F2 Send "nn" characters followed by "xx" key or function code, starting from current
F3 Send up to but not including "ss" character (Search and Send) starting from current
F4 Send "xx" character "nn" times (Insert) leaving cursor in current cursor position.
3-20
Must send
00012345
cursor position. Syntax = F1xx (xx stands for the hex value for an ASCII code, see
the "Hex to ASCII Conversion Chart" earlier in this chapter.)
cursor position. Syntax = F2nnxx (nn stands for the numeric value (00-99) for the
number of characters and xx stands for the hex value for an ASCII code.)
cursor position, leaving cursor pointing to "ss" character followed by "xx" key or
function code. Syntax = F3ssxx (ss and xx both stand for the hex values for ASCII
codes.)
Syntax = F4xxnn (xx stands for the hex value for an ASCII code, and nn is the
numeric value (00-99) for the number of times it should be sent.)
