Sabre 1552 Scanner and MicroBar 9745 Base Station System Manual
Connectors and Pinouts
This section provides the back view of the base and the auxiliary RS-232/wand
emulation connector, the keyboard/terminal and RS-232 (host port) connector, and the
external power connector.
Base: Back View
Aux RS-232, service port,
and wand emulation
output connector
(auxiliary port)
8-6
Keyboard/terminal
and RS-232 connector
(host port)
Antenna
External power
connector
(power port
optional)
1552S015.eps
