Sabre 1552 Scanner and MicroBar 9745 Base Station System Manual
1-12

Understanding the Scanner LED

Sequence
Green LED on
Green LED on, 2 seconds
Green LED blinks, 2 seconds
Green LED on, 5 seconds
Green LED blinks, 5 seconds
Yellow LED on
Yellow LED blinks

Understanding the Scanner Beeps

Sequence
No beep
1 beep
Clicking, then 1 beep
Clicking only
2 beeps, clicks, then 1 beep
3 beeps, same tone
3 beeps, 2 high and 1 low tone
4 beeps, low, high, low, high
tones
Meaning
Trigger pulled, out of range
Successful decode and communication
Successful decode with unsuccessful communication, or
unsuccessful clear to scanner
Enter/exit programming mode, successful parameter change
in programming mode
Unsuccessful parameter change in programming mode
Scanning, trigger pulled (in or out of range)
Low battery (trigger pulled)
Meaning
No scanning, scanning, or low battery (trigger pulled)
Successful decode and communication
Successful reassociation
Unsuccessful reassociation
Successful association to base
Unsuccessful association to base (10th scanner), out of
range, or no network
Enter/exit programming mode or successful association to
base. Successful or unsuccessful parameter change in
programming mode.
Communication error: successful decode with possible
unsuccessful communication to base. Check host to
determine if data arrived properly.
