MicroBar 9745 Base Station Specifications

Parameter
Dimensions
Weight
LED Indicators
Beeper
Operating Voltage
Power Consumption
Noise Immunity
Temperature Ranges
Humidity
Housing Material
Sealing
Mechanical Shock
ESD Sensitivity
Reliability

Radio Specifications

Parameter
Frequency
Data Rates
Response Time
Specification
Height 3.6 cm (1.4 in)
Width 10.2 cm (4.0 in)
Length 11.5 cm (4.5 in)
206 g (7.25 oz) without cable
One
None
+4.0 to 14.0 VDC
Standard Mode 285 mA (typical ) @ 5 VDC
Low Power Mode 140 mA (typical) @ 5 VDC
100 mV peak to peak
Operating: -20ºC to +50ºC (-4ºF to +122ºF)
Storage: -40ºC to +70ºC (-4ºF to +158ºF)
0 to 95% relative humidity (non-condensing)
GE Cycloloy C2800 or C2950 Standard Flow
IP 53 (Water and Dust Resistant)
26 drops from 1.2 m (4 ft) to concrete
15 kV to any external surface
MTBF = 50,000 hours (ground benign)
Specification
2.00 to 2.4835 GHz (ISM Band)
Frequency Hopping Carrier
1 Mbps
Standard Mode 10 mS typical
Low Power Mode 65 mS typical
