Appendix E Repacking the Cisco Nexus 7000 Series Switch for Shipment
1 Pull out either door handle.
Press the locking button on the back side of the door (behind the opened latch handle) so that the
b.
latch handle flattens to the front side of the door.
c. Hold the opened side of the door with one hand and use your other hand to open the latch handle on
the hinged side of the door until the handle clicks. Use both hands to remove the door from the
chassis.
Press the locking button on the inside surface of the door behind the opened latch to flatten the latch
d.
handle to the front side of the door.
Wrap the door in the bubble wrap included in the front-door and air-intake-frame kit. Set this by the
e.
kit for packing later in this process.
Remove the bottom hinge bracket by removing four screws that attach it to the chassis and four
f.
screws that attach it to the right and left cable management frames (two screws for each frame) as
shown in
screws in a bag for small door parts.
Figure E-6
OL-23069-07
Figure E-6. Place the bracket with the front door wrapped in bubble wrap and put the
Removing the Bottom Hinge Bracket from the Chassis
Cisco Nexus 7000 Series Hardware Installation and Reference Guide
Repacking the System Components
2 Fully rotate the door away from the chassis.
