PANEL DESCRIPTION

■ Function display

Push [MENU] to toggle between M1 (Menu 1) and M2
(Menu 2).
• The set of functions assigned to the function switches
changes, according to the selected menu and oper-
ating mode.
M1 (Menu 1)
D
(Mode: SSB)
AGC
(Mode: SSB-D)
AGC
(Mode: CW)
AGC
(Mode: RTTY)
AGC
(Mode: AM)
AGC
(Mode: FM)
AGC
13
TBW SCP
1 ⁄ 4 SCP
1 ⁄ 4 KEY SCP
1 ⁄ 4 RTTY SCP
SCP
TON SCP
Push to select the functions displayed above switches
([F-1] to [F-5]).
• Functions vary, depending on the operating mode.
Function keys on M1 (Menu 1)
D
AGC KEY [AGC](F-1) (p. 56)
(Mode: SSB/CW/RTTY/AM/FM)
➥ Push to select the time constant of the AGC circuit.
➥ Hold down for 1 second to display the "AGC"
screen.
1 ⁄ TUNING FUNCTION KEY [
4
(Mode: SSB-D/CW/RTTY)
Push to turn the 1 ⁄ Tuning function ON or OFF.
4
• " " is displayed when the
TRANSMISSION BANDWIDTH KEY [TBW](F-4)
(p. 64)
(Mode: SSB)
➥ Push to display the selected transmission band-
width.
➥ Hold down for 1 second to select the transmission
bandwidth.
• Wide (WIDE), mid (MID) and narrow (NAR) bandwidths
are selectable.
MEMORY KEYER MENU KEY [KEY](F-4) (p. 38)
(Mode: CW)
Push to display the "KEY" screen (Memory Keyer) or
the "SEND" screen (Keyer Send), depending on the
"KEYER 1st Menu" setting in the Set mode (p. 88).
RTTY MENU KEY [RTTY](F-4) (p. 45)
(Mode: RTTY)
Push to display the "RTTY" screen.
TONE SQUELCH KEY [TON](F-4) (p. 50)
(Mode: FM)
➥ Push to select a tone function between subaudible
(repeater) tone and tone squelch.
➥ Hold down for 1 second to display the "TON" screen
(Tone) of the selected tone function.
BAND SCOPE FUNCTION KEY [SCP](F-5) (p. 54)
(Mode: SSB/CW/RTTY/AM/FM)
Push to display the "SCP" screen (Band Scope).
1 ⁄ ](F-3) (p. 27)
4
1 ⁄ Tuning function is ON.
4
