10
SET MODE
■ Set mode description (Continued)
38. USB Audio SQL
Select whether or not to output the audio from the
[USB] connector on the rear panel, according to the
squelch state.
The same audio signals are sent from the [USB] con-
nector and the [ACC] sockets.
- The beep tones and the voice synthesizer announce-
ments are not sent.
- The received audio output level cannot be adjusted
with the [AF] control.
• OFF (OPEN) : The received audio is always sent,
• ON : The received audio is sent when the
39. USB MOD Level
Set the input modulation level of the [USB] connector
to between 0% and 100% in 1% steps.
40. DATA OFF MOD
Select the desired connector(s) for data modulation
input in the data OFF mode.
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC] (pin 11).
• MIC, ACC : Use the signals from [MIC] and [ACC]
(pin 11).
• USB : Use the signals from [USB].
41. DATA MOD
Select the desired connector(s) for data modulation
input in the data mode.
• MIC : Use the signals from [MIC].
• ACC : Use the signals from [ACC] (pin 11).
• MIC, ACC : Use the signals from [MIC] and [ACC]
(pin 11).
• USB : Use the signals from [USB].
42. CI-V Baud Rate
Set the CI-V data transfer rate between 300, 1200,
4800, 9600, 19200 bps and "Auto."
When "Auto" is selected, the baud rate is automatically
set according to the data rate of the connected con-
troller.
89
(Default: OFF(OPEN))
regardless of the squelch state.
squelch is open.
(Default: 50%)
(Default: MIC,ACC)
(Default: ACC)
(Default: Auto)
43. CI-V Address
To distinguish equipment, each CI-V transceiver has
its own Icom standard address in hexadecimal code.
The IC-7410's address is 80h.
When 2 or more IC-7410's are connected to an op-
tional CT-17 - level converter, rotate [DIAL] to se-
ci v
lect a different address for each IC-7410; the range is
01h to DFh.
44. CI-V Transceive
Turn the transceive operation using the CI-V system
ON or OFF.
When this item is set to ON, changing the frequency,
operating mode, etc. on the IC-7410 automatically
changes those settings on other Icom HF transceivers
or receivers, and vice versa.
• OFF : Transceive operation OFF
• ON : Transceive operation ON
45. USB Serial Func
Select the function for the USB port on the rear panel.
• CI-V : Used to send CI-V commands
• RTTY : In the RTTY mode, used to send RTTY de-
coded signal.
46. RTTY Decode Baud
Set the RTTY decode monitor speed to 300, 1200,
4800, 9600 or 19200 bps.
47. Calibration Marker
Use as a simple frequency check of the transceiver.
See page 98 for calibration procedure.
NOTE: Turn OFF the calibration marker after check-
ing the frequency of the transceiver.
• OFF : Calibration marker OFF
• ON : Calibration marker ON
48.

REF Adjust

During frequency calibration, set the internal refer-
ence frequency to between 0% and 100% range in 1%
steps.
NOTE: The default setting is different for each
transceiver.
(Default: 80h)
(Default: ON)
(Default: CI-V)
.
(Default: 9600)
(Default: OFF)
